Home ProductsStainless Steel Seamless Tube

ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications

ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications

  • ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
  • ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
  • ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
  • ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
  • ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
  • ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A213 TP316L
Payment & Shipping Terms:
Minimum Order Quantity: 100KG
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 10-30 Days
Payment Terms: T/T,L/C
Supply Ability: 1000T /Month
Contact Now
All Products
Stainless Steel Seamless Pipe (324)
Stainless Steel Seamless Tube (318)
Duplex Stainless Steel Pipe (134)
Duplex Stainless Steel Tube (36)
Needle Tube (149)
Fin Tube (692)
Heat Exchanger (23)
Heat Exchanger Tube (456)
Heat Exchanger Tube Bundle (46)
Heat Exchanger Tubesheet (122)
Heat Exchanger Baffle (39)
Air Cooler (10)
Pressure Vessel (4)
Stainless Steel Welded Pipe (59)
Stainless Steel Welded Tube (127)
Nickel Alloy Pipe (270)
Nickel Alloy Tube (95)
Copper Alloy Tube (247)
Alloy Steel Tube (208)
Titanium Tube (18)
Bright Annealed Tube (171)
Boiler Tube (151)
Steel Fitting (852)
Steel Flange (650)
Others (404)
Cladding Parts (8)
Detailed Product Description
Standard: ASTM A213 / ASME SA213 Material: TP316L (UNS S31603), Austenitic
Type: Seamless (SMLS) Stainless Steel Tube OD（Outside Diameter）: 6mm – 159mm
WT（Wall Thickness）: 1.0mm – 10mm, SCH 10S – SCH 80S Length: 6m Or Cut-to-Length
Ends: Plain End (PE), Beveled End (BE) Applications: Heat Exchangers, Boilers, Condensers, Chemical Processing, High Temp/Corrosion Service
Highlight:

ASTM A213 TP316L stainless steel pipe

,

seamless stainless steel pipe industrial grade

,

high corrosion resistance stainless steel pipe

ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications
  • Material & Standard:ASTM A213 TP316L stainless steel, low carbon molybdenum-containing austenitic stainless steel, compliant with international industrial pipe standards, with stable chemical composition and mechanical properties.
  • Structure & Process:Cold drawn/hot rolled seamless pipe, no welding seam, uniform wall thickness, smooth inner/outer surface, precision processed to ensure high pressure and impact resistance.
  • Key Performance:Excellent corrosion resistance (especially to chloride ion pitting corrosion), good high/low temperature toughness, non-magnetic, and easy to weld and process for various industrial fabrication.
  • Specifications:Customizable outer diameter (OD: 6mm-630mm), wall thickness (WT: 1mm-50mm), length (6m/12m fixed or cut-to-length as required); surface finish: pickled & passivated (default), polished, sandblasted optional.
  • Application Scenarios:Widely used in chemical, petroleum, food and beverage, pharmaceutical, marine engineering, heat exchange systems and other industries for conveying corrosive media, high-temperature steam and pure fluids.
Quality Inspection Items & Standards
Inspection Stage Inspection Stage Inspection Standard Inspection Method / Report
In-production Inspection Dimensional Tolerance Detection ASTM A213 100% inspection by caliper/micrometer/ultrasonic thickness gauge
Chemical Composition (WT. %)
Element C Si Mn P S Cr Ni Mo N Fe
Range ≤0.030 ≤1.00 ≤2.00 ≤0.045 ≤0.030 16.00-18.00 10.00-14.00 2.00-3.00 ≤0.10 Bal.
Typical Value 0.025 0.50 1.50 0.030 0.010 17.00 12.00 2.50 0.05 Bal.
Supplementary Notes:
  1. All products are seamless stainless steel tubes without welding seams, ensuring no leakage risk under high-pressure working conditions.
  2. Value-added processing services such as cut-to-length, beveling, spray marking can be provided as required, with no extra processing fee for bulk orders.
  3. The Material Test Certificate (MTC/COA) includes chemical composition and mechanical property test data of each batch of goods, with complete traceability.
ASTM A213 TP316L Seamless Stainless Steel Tube for Heat Exchangers, Boilers and High Corrosion Resistance Applications 0

Tag:

seamless stainless steel tube,

seamless boiler tubes,

stainless steel seamless pipes
