ASTM A182 F55 S32760 Weld Neck Flange RTJ EN 1.4501 X2CrNiMoCuWN25-7-4

Product Details:

Place of Origin:	China , USA, UK
Brand Name:	YUHONG
Certification:	API, PED,
Model Number:	A 182, GR F1, F11, F22, F5, F9, F91, Class : 150#, 300#,400 #,600#,900#, 1500# & 2500 #.

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	NEGITABLE
Packaging Details:	PLY-WOODEN CASE
Delivery Time:	7DAYS
Payment Terms:	T/T , LC
Supply Ability:	100 TONS PER MONTH

Contact Now

All Products

Stainless Steel Seamless Pipe (324)

Stainless Steel Seamless Tube (318)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (36)

Needle Tube (149)

Fin Tube (692)

Heat Exchanger (23)

Heat Exchanger Tube (456)

Heat Exchanger Tube Bundle (46)

Heat Exchanger Tubesheet (122)

Heat Exchanger Baffle (39)

Air Cooler (10)

Pressure Vessel (4)

Stainless Steel Welded Pipe (59)

Stainless Steel Welded Tube (127)

Nickel Alloy Pipe (270)

Nickel Alloy Tube (95)

Copper Alloy Tube (247)

Alloy Steel Tube (208)

Titanium Tube (18)

Bright Annealed Tube (171)

Boiler Tube (151)

Steel Fitting (852)

Steel Flange (650)

Others (404)

Cladding Parts (8)

Detailed Product Description

Highlight:

ASTM A182 F55 weld neck flange

S32760 RTJ steel flange

EN 1.4501 X2CrNiMoCuWN25-7-4 flange

ASTM A182 F55 S32760 Weld Neck Flange RTJ EN 1.4501 X2CrNiMoCuWN25-7-4

ASTM A213 TP321H bright seamless tube is a special type of pipe designed to solve the dual challenges of "high-temperature strength" and "corrosion resistance."

Its most precise application is in critical heat exchange equipment in petrochemical, power plant boiler, and other fields requiring high temperature, high pressure, and strict resistance to intergranular corrosion, especially in operating conditions above 540°C where the equipment may face "wet-dry alternation" or corrosive condensate generation.

The following are its core application scenarios and reasons for choosing it:

The "H" in TP321H represents the high-temperature grade. Unlike ordinary 321 stainless steel with a carbon content ≤0.08%, 321H has a carbon content controlled within a higher range of 0.04-0.10%, ensuring higher creep rupture strength and endurance strength at high temperatures. Simultaneously, the addition of titanium as a stabilizing element enables it to resist intergranular corrosion.

Bright annealing treatment results in a smooth, oxide-free inner and outer surface with a high degree of surface finish. For heat exchange tubes, the inner wall is smoother, the resistance to medium flow is smaller, and it is less prone to scaling.

ASTM A182 F55Chemical Composition
Element	Composition (% by weight)
Carbon (C)	0.030 max
Manganese (Mn)	1.00 max
Phosphorus (P)	0.035 max
Sulfur (S)	0.020 max
Silicon (Si)	1.00 max
Chromium (Cr)	24.0 – 26.0
Nickel (Ni)	6.0 – 8.0
Molybdenum (Mo)	3.0 – 4.0
Copper (Cu)	0.50 – 1.00
Tungsten (W)	0.50 – 1.00
Nitrogen (N)	0.20 – 0.30
Iron (Fe)	Balance

ASTM A182 F55 Mechanical Properties
Property	Value
Tensile Strength	860 MPa (125 ksi) min
Yield Strength (0.2% offset)	655 MPa (95 ksi) min
Elongation (in 2 inches or 50 mm)	16% min
Reduction of Area	50% min
Hardness	≤ 28 HRC (Rockwell C)
Impact Toughness	Typically 100J+ at -46°C (often specified for critical services)

Application:

Marine Engineering: Such as offshore oil platforms and subsea pipeline systems, used for processing mixtures of seawater and crude oil.
Oil and Gas: Particularly suitable for wellhead equipment, pipelines, and processing facilities in acidic oil and gas fields containing hydrogen sulfide (H₂S).
Chemical Processing Industry: Used for reactors, heat exchangers, and pipeline connections for processing highly corrosive media such as organic or inorganic acids containing chlorides.
Seawater Desalination Plants: Used for connecting seawater-resistant pipelines and equipment in high-pressure reverse osmosis or distillation seawater desalination processes.

ASTM A182 F55 S32760 Weld Neck Flange RTJ EN 1.4501 X2CrNiMoCuWN25-7-4 1
