STEEL FLANGES ASTM B564 NICKLE ALLOY MONEL400 UNS N04400 WNRTJ FLANGE

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	API ,PED
Model Number:	N04400,MONEL400

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Packaging Details:	PLY-WOODEN CASE,PALLET
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (337)

Stainless Steel Seamless Tube (326)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (38)

Needle Tube (162)

Fin Tube (708)

Heat Exchanger (31)

Heat Exchanger Tube (468)

Heat Exchanger Tube Bundle (50)

Heat Exchanger Tubesheet (125)

Heat Exchanger Baffle (39)

Air Cooler (13)

Pressure Vessel (4)

Stainless Steel Welded Pipe (61)

Stainless Steel Welded Tube (132)

Nickel Alloy Pipe (275)

Nickel Alloy Tube (103)

Copper Alloy Tube (251)

Alloy Steel Tube (212)

Titanium Tube (20)

Bright Annealed Tube (173)

Boiler Tube (152)

Steel Fitting (863)

Steel Flange (662)

Others (406)

Cladding Parts (9)

Detailed Product Description

Flanges Size::

1/8" NB TO 48"NB.

CLASS:

150#,300#,400#,600#,900#,1500#,2500#

Material:

Nickel Alloys,Monel400,N04400

TYPE:

SORF,SOFF,BLIND,WNRF,WNFF,BLRF,BLFF

Highlight:

ASTM B564 Monel400 steel flange

Nickel alloy WNRTJ flange

UNS N04400 RTJ flange

STEEL FLANGES ASTM B564 NICKLE ALLOY MONEL400 UNS N04400 WNRTJ FLANGE

A Monel 400 flange is a pipe flange made from Monel 400, a nickel-copper alloy known for its outstanding corrosion resistance, particularly in marine and chemical environments.

A flange is a mechanical component used to connect pipes, valves, pumps, and other equipment to form a piping system. Monel 400 flanges combine the standard functionality of a flange with the unique material properties of the Monel 400 alloy.

Standards and Specifications:

- ASTM B564: Standard specification for nickel alloy forgings.

- ASME B16.5: Pipe flanges and flanged fittings.

STEEL FLANGES ASTM B564 NICKLE ALLOY MONEL400 UNS N04400 WNRTJ FLANGE 0

Feature	Monel 400 Flange
Main Alloying Elements	Nickel (63+%) & Copper (28-34%)
Corrosion Resistance	Superior in reducing environments (e.g., dilute sulfuric acid). Excellent in seawater and against chloride stress corrosion cracking.
Magnetic Property	Non-magnetic (essential for specific applications).
Typical Cost	High (due to high nickel content).
Primary Niche	Severe corrosive conditions in marine, chemical, and cryogenic services.

Key Limitations to Consider:

- Not for Oxidizing Acids: Monel 400 performs poorly in strongly oxidizing environments, such as nitric acid and ferric chloride solutions.

- Ammonia Systems: It is also rapidly attacked by ammonia systems and is not recommended for such applications.

Advantages:

Marine & Offshore:Seawater cooling systems, pump and valve components, propeller shafts, and piping on ships and oil rigs.
Chemical & Petrochemical Processing:Handling sulfuric and hydrofluoric acids, chlorinated solvents, and other corrosive media.
Aerospace & Nuclear:Used in critical systems like fuel and hydraulic lines, as well as in nuclear fuel refining plants.
Oil & Gas:Sour gas (H₂S) service, crude oil distillation towers, and well-drilling equipment.

Test Certificate

Manufacturer Test Certificate as per EN 10204 / 3.1B

STEEL FLANGES ASTM B564 NICKLE ALLOY MONEL400 UNS N04400 WNRTJ FLANGE 1
