Titanium tube Titanium Alloy Tube ASME SB338 UNS 50400 for Condenser,Heat Exchanger evaporators, chemical systems, marine equipment, desalination plants, power plants, industrial process equipment

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	SB338 Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Wooden Box package
Delivery Time:	35-40 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	1000Ton per month

Contact Now

All Products

Stainless Steel Seamless Pipe (336)

Stainless Steel Seamless Tube (326)

Duplex Stainless Steel Pipe (134)

Duplex Stainless Steel Tube (38)

Needle Tube (163)

Fin Tube (710)

Heat Exchanger (31)

Heat Exchanger Tube (468)

Heat Exchanger Tube Bundle (50)

Heat Exchanger Tubesheet (125)

Heat Exchanger Baffle (39)

Air Cooler (13)

Pressure Vessel (4)

Stainless Steel Welded Pipe (61)

Stainless Steel Welded Tube (132)

Nickel Alloy Pipe (276)

Nickel Alloy Tube (104)

Copper Alloy Tube (251)

Alloy Steel Tube (212)

Titanium Tube (21)

Bright Annealed Tube (173)

Boiler Tube (153)

Steel Fitting (864)

Steel Flange (663)

Others (407)

Cladding Parts (9)

Detailed Product Description

SPEC:	ASME SB338	Material:	Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr6
Size:	As Per Client's Request	Application:	Condenser,Heat Exchanger
Technical:	Hot Rolled	Package:	Plywood Box Package
Highlight:	Titanium tube for heat exchangers , Titanium alloy tube ASME SB338 , Titanium tube for marine equipment

Titanium tube Titanium Alloy Tube ASME SB338 UNS 50400 for Condenser,Heat Exchanger evaporators, chemical systems, marine equipment, desalination plants, power plants, industrial process equipment

Titanium supplies ASME SB338 titanium tubing, ASME SB338 seamless titanium tube, ASME SB338 welded titanium tube, ASME SB338 titanium alloy tube, ASME SB338 heat exchanger tube, and ASME SB338 condenser tube as per customer specifications used mainly in heat exchangers, condensers, evaporators, chemical systems, marine equipment, desalination plants, power plants, and industrial process equipment.

Item	Titanium Tube
Standard	ASTM B861-05,ASTM B862-05,ASTM B338-06,GB/T3625-2007, GB/T3624-2007,JISH4630-2001,JISH4631-2009,etc
Material	TA1,Gr.1,TP270H,BT1-00,TA2,TP340H,Gr.2,BT1-0,Ti2,TA3,Gr.3, TP480H,Ti3,TA9,Gr.7,TA10,Gr.12,etc
Size	OD:2-910mm WT:0.2-100mm Length:1-10m,or as reqired
Package	Standard export package,suit for air and sea transport,by wooden box or as required
Price term	Ex-Work,FOB,CNF,CFR,CIF,etc
Export to	Poland ,India,Singapore,Indonesia,Dubai,Ukraine,Saudi Arabia,Spain, Brazil,Korea,Thailand,USA,UK,Canada,Ireland,etc
MOQ	100Kg
Application	Because of the titanium excellent corrosion resistance, titanium material widely used in petroleum,chemical,salt,Pharmaceutical, metallurgy,electronic,aviation, aerospace, Marine,etc.
Contact	If you have any question,please feel free to contact us . We are sure your inquiry or requirements will get prompt attention.

Titanium Seamless Tube Specification

Dimension	Outer Diameter	Thickness	Length
Size Range:	0.5mm – 330mm	0.4mm – 10mm	Max 15m
Manufacturing Standards	ASTM B338, ASTM B861, DIN 17 861

Titanium tube Chemical requirements

	Tensile strength		Yeild strength min max		Elongation
	MPa	kis	ksi Mpa	ksi Mpa	%
Gr 1	240	35	20(138)	45(310)	24
Gr 2	345	50	40(275)	65(450)	20
Gr 3	450	65	55(380)	80(550)	18
Gr 7	345	50	40(275)	65(450)	20
Gr 9	620	90	70(483)	...	15
Gr11	240	35	20(138)	45(310)	24
Gr12	483	70	50(345)	...	18
Gr13	275	40	25(170)	...	24
Gr14	410	60	40(275)	...	20

Titanium Seamles Tubes Surface Finish

Surface Finish		Internal Surface(ID)		Exterbal Surface(OD)
		Roughness Average(RA)		Roughness Average(RA)
		μ inch	μm	μ inch	μm
MP	Mechanical Polish	40,32,25,20	1.0,0.8,0.6,0.5	32	0.8
EP	Electro Polish	15,10,7,5	0.38,0.25,0.20;0.13	32	0.8
BA	Beight Annealed	40,32,25,20	1.0,0.8,0.6,0.5	32	0.8
AP	Annealed & Pickled	Not defined	Not defined	40 or Not defined	1.0 or Not defined

Features of Titanium Oval Tubing

Great strength
Sturdy construction
Dimensional accuracy
Corrosion resistance
Durability
Effective functionality

Titanium Tube Application

Welded or Seamless tube for other fabricated pipe spools
Seamless Titanium Grade 2 Tube for Heat Exchangers.
Tube for bicycles, golf clubs and other sporting items, condensers, instrumentation.
Welded Titanium Grade 1 or 2 tube for an exhaust system in your performance street or racing car.
Welded or Seamless Pipe for HPAL plants in Titanium Grade 2 or Titanium Grade 12
Forgings, Fittings and Flanges are also available in most grades of Titanium.
