ASME SB622 UNS N10276 Nickel Alloy Seamless Tube Hastelloy C276 Tube Heat Exchanger Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS
Model Number:	ASME SB622 Hastelloy C276 Seamless Tube

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7 DAYS
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (355)

Stainless Steel Seamless Tube (354)

Duplex Stainless Steel Pipe (144)

Duplex Stainless Steel Tube (41)

Needle Tube (175)

Fin Tube (765)

Heat Exchanger (45)

Heat Exchanger Tube (485)

Heat Exchanger Tube Bundle (57)

Heat Exchanger Tubesheet (133)

Heat Exchanger Baffle (39)

Air Cooler (14)

Pressure Vessel (4)

Stainless Steel Welded Pipe (62)

Stainless Steel Welded Tube (136)

Nickel Alloy Pipe (280)

Nickel Alloy Tube (114)

Copper Alloy Tube (259)

Alloy Steel Tube (229)

Titanium Tube (22)

Bright Annealed Tube (165)

Boiler Tube (166)

Steel Fitting (888)

Steel Flange (693)

Others (413)

Cladding Parts (9)

Detailed Product Description

Product Name:	Nickel Alloy Tube	Standard:	ASTM B622, ASME SB622
Material:	Hastelloy C276, UNS N10276, DIN 2.4819	O.D.:	1/4" To 3"
W.T.:	0.065" To 3.05"	Length:	Single Random, Double Random & Cut Length
Type:	Seamless	Form:	Straight, U Bend
End:	Plain End, Beveled End, Treaded
High Light:	ASME SB622 UNS N10276 Nickel Alloy Tube, Hastelloy C276 Seamless Tube

ASTM B622 / ASME SB622 Alloy C276 / UNS N10276 / DIN 2.4819 Seamless Hastelloy Tube

YUHONG GROUP is specialized in manufacturing and supplying heat exchanger tube/boiler tube/condenser tube. Our products has exported more than 55 countries till now and won good reputation among the clients. ASME SB622 UNS N10276 Nickel Alloy Seamless Tube Hastelloy C276 Tube Heat Exchanger Tube is a seamless, nickel-base alloy tube made from UNS N10276, commonly known as Hastelloy C276 / Alloy C276, manufactured according to ASME SB622 (the ASME version of ASTM B622), and intended mainly for heat exchanger service.

In simple terms, it is a weldless Hastelloy C276 tube produced to the ASME SB622 specification for use in shell-and-tube heat exchangers, condensers, evaporators, and similar corrosion-resistant heat-transfer equipment.

Equivalent Grade of ASME SB622 UNS N10276 Nickel Alloy Seamless Tube Hastelloy C276 Tube

STANDARD	UNS	WNR.	AFNOR	EN	JIS	OR	GOST
Hastelloy C276	N10276	2.4819	-	NiMo16Cr15W	NW 0276	ЭП760	ХН65МВУ

Chemical Composition of ASME SB622 UNS N10276 Nickel Alloy Seamless Tube Hastelloy C276 Tube

Hastelloy C276	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy C276	Balance	0.010 max	15.00 – 17.00	1.00 max	0.08 max	4.00 – 7.00	0.04 max	0.03 max	2.5 max	14.50 – 16.50

Mechanical Properties of ASME SB622 UNS N10276 Nickel Alloy Seamless Tube Hastelloy C276 Tube

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.89 g/cm3	1370 °C (2500 °F)	Psi – 52,000 , MPa – 355	Psi – 1,15,000 , MPa – 790	40 %

Key Characteristics of Using Grade UNS N10276/ Hastelloy C276

Excellent resistance to oxidizing and reducing acids
Outstanding resistance to chlorides, seawater, brine, and hypochlorite
Resistant to pitting, crevice corrosion, and stress corrosion cracking
Good resistance to sulfuric acid, hydrochloric acid, phosphoric acid, acetic acid, formic acid
Good weldability using matching fillers such as ERNiCrMo-4 / ENiCrMo-4
Good high-temperature stability
Preferred for severe corrosion and pressure-tight heat exchanger service

Choose ASME SB622 UNS N10276 / Hastelloy C276 seamless heat exchanger tube when the service is too corrosive or too critical for stainless steel. Main situation:

When	Short reason
Strong acids: HCl, H₂SO₄, H₃PO₄, acetic, formic, mixed acids	C276 resists both oxidizing and reducing acids.
Chlorides, seawater, brine, hypochlorite	Excellent resistance to pitting, crevice corrosion, and SCC.
Chemical / petrochemical / pharmaceutical heat exchangers	Handles aggressive media where 316L, 904L, duplex, or 6Mo may fail.
High-pressure or critical heat exchanger service	Seamless tube avoids weld-seam weakness and leakage risk.
Code requires ASME SB622 / ASTM B622	Ensures pressure-code compliance and traceability.
High temperature + corrosive environment	Good high-temperature corrosion resistance and stability.
U-bent or severe bending heat exchanger tubes	Seamless C276 has good ductility and uniformity.
