STAINLESS STEEL FITTING ASTM B16.11 NIPPLE COUPLING ELBOW TEE BUSH UNION F53 3000#

Name: STAINLESS STEEL FITTING ASTM B16.11 NIPPLE COUPLING ELBOW TEE BUSH UNION F53 3000#
Brand: YUHONG
SKU: NIPPLE , COUPLING, ELBOW , TEE, BUSH, UNION,HEX PLUG
Rating: 4.6 (153 reviews)

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	BV, LR, ABS, DNV, TS, CCS, KR
Model Number:	NIPPLE , COUPLING, ELBOW , TEE, BUSH, UNION,HEX PLUG

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Packaging Details:	PALLET,PLYWOOD CASE
Delivery Time:	7DAYS
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (261)

Stainless Steel Seamless Tube (242)

Finned Tube (501)

Heat Exchanger Tube (188)

Tube Bundle (29)

Heat Exchanger Parts (163)

Stainless Steel Welded Pipe (51)

Stainless Steel Welded Tube (101)

Duplex Stainless Steel Pipe (142)

Alloy Steel Tube (145)

Bright Annealed Tube (155)

Copper Alloy Tube (182)

Nickel Alloy Pipe (313)

Needle Tube (29)

U Bend Tube (202)

Boiler Tube (118)

Steel Fitting (693)

Steel Flange (506)

Precision Steel Strip (29)

Alloy Wires (271)

Others (75)

Detailed Product Description

Material:	F51 / F53 / F55 / F60 /F44	Type:	NIPPLE , COUPLING , ELBOW , TEE, BUSH, UNION, SUPER DUPLEX FITTING
End:	SW,NPT,FNPT,MNPT,SCREW	STANDARD:	A182 B16.11,MSS SP-93..
CLASS:	3000#,6000#...	Usage:	Joining Pipe Lines,Oil Gas Water Industrial,oil,gas,Water
High Light:	butt welding fittings , forged steel fittings

STAINLESS STEEL FITTING ASTM B16.11 NIPPLE COUPLING ELBOW TEE BUSH UNION F53 3000#

Square Socket Reducer Inserts , Stainlesss, Carbon Steel , Duplex Steel , Nickel Alloy Steel .

Sr. No.	Material	Size	Sch. & Class	Specification	Item
1.	Forged Stainless Steel	15 NB To 100 NB	3000, 6000 & 9000 LBS	A-182 S/W & SCRD ANSI B16.11	Elbow - 90^o & 45^o Tee - Equal & Reducing Union Cross Coupling - Full & Half Socket Reducing CAP Plug-Hex & Square Nipples (Hex/Reducing) Sokolet & Weldolet Bush Fasteners
2.	Forged Alloy Steel	15 NB To 100 NB	3000, 6000 & 9000 LBS	A-182 S/W & SCRD ANSI B16.11
3.	Forged Carbon Steel	15 NB To 100 NB	3000, 6000 & 9000 LBS	A-105 S/W & SCRD ANSI B16.11

Products Socket Reducer Inserts

Product Pictures and Drawings


Type1		Type2

Dimensional Data

Socket weld reducer Inserts availbale in class 3000, 6000 and 9000

			Class 3000				Class 6000				Class 9000
Nominal Pipe Size	C	D	Fitting Type	A	B	E	Fitting Type	A	B	E	Fitting Type	A	B	E
3/8 x 1/4	0.675	0.555	1	7/16	3/4	15/16	1	7/16	7/8	1
1/2 x 3/8	0.850	0.690	1	7/16	13/16	1 1/16	1	7/16	15/16	1 3/16
1/2 x 1/4	0.850	0.555	1	7/16	13/16	15/16	1	7/16	7/8	1
3/4 x 1/2	1.060	0.855	1	7/16	7/8	1 5/16	1	7/16	1 1/16	1 3/8	1	7/16	1 3/16	1 3/4
3/4 x 3/8	1.060	0.690	2	7/16	5/8	-	1	7/16	7/8	1 3/16
3/4 x 1/4	1.060	0.555	2	3/8	11/16	-	2	3/8	7/8	-
1 x 3/4	1.325	1.065	1	9/16	15/16	1 1/2	1	9/16	1 1/8	1 11/16	1	9/16	1 1/4	2
1 x 1/2	1.325	0.855	2	1/2	5/8	-	1	7/16	1 1/8	1 3/8	1	7/16	1 1/8	1 3/4
1 x 3/8	1.325	0.690	2	7/16	11/16	-	2	1/2	7/8	-
1 x 1/4	1.325	0.555	2	3/8	3/4	-	2	3/8	15/16	-
1 1/4 x 1	1.670	1.330	1	9/16	1	1 7/8	1	9/16	1 3/16	2	1	9/16	1 3/8	2 3/8
1 1/4 x 3/4	1.670	1.065	2	9/16	11/16	-	2	9/16	13/16	-	1	9/16	1 3/16	2
1 1/4 x 1/2	1.670	0.855	2	1/2	3/4	-	2	1/2	7/8	-	2	1/2	7/8	-
1 1/4 x 3/8	1.670	0.690	2	7/16	13/16	-	2	7/16	15/16	-
1 1/4 x 1/4	1.670	0.555	2	3/8	7/8	-	2	3/8	1	-
1 1/2 x 1 1/4	1.910	1.675	1	9/16	1 1/8	2 1/4	1	9/16	1 3/8	2 3/8	1	9/16	1 5/8	2 3/4
1 1/2 x 1	1.910	1.330	2	5/8	11/16	-	1	9/16	1 3/16	2	1	9/16	1 3/8	2 3/8
1 1/2 x 3/4	1.910	1.065	2	9/16	3/4	-	2	9/16	1	-	2	9/16	1	-
1 1/2 x 1/2	1.910	0.855	2	1/2	13/16	-	2	1/2	1 1/16	-	2	9/16	1	-
1 1/2 x 3/8	1.910	0.690	2	7/16	7/8	-	2	7/16	1 1/8	-
2 x 1 1/2	2.385	1.915	1	9/16	1 1/4	2 1/2	1	9/16	1 7/8	2 11/16	1	9/16	2 1/16	3
2 x 1 1/4	2.385	1.675	2	11/16	13/16	-	2	7/8	15/16	-	1	9/16	2	2 3/4
2 x 1	2.385	1.330	2	5/8	7/8	-	2	13/16	1	-	2	13/16	1	-
2 x 3/4	2.385	1.065	2	9/16	15/16	-	2	3/4	1 1/16	-	2	3/4	1 1/16	-
2 x 1/2	2.385	0.855	2	1/2	1	-	2	11/16	1 1/8	-	2	11/16	1 1/8	-
