ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET ASME SB165 N04400 PIPE

ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET ASME SB165 N04400 PIPE

    • ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE
    • ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE
    • ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE
    • ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE
  • ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE

    Product Details:

    Place of Origin: CHINA
    Brand Name: YUHONG
    Certification: ABS, BV, DNV, GL, LR, SGS, IEI
    Model Number: ASTM B165 N04400 SMLS PIPE 273X9.27X5000-5800MM

    Payment & Shipping Terms:

    Minimum Order Quantity: 50KGS
    Packaging Details: Ply-wooden Case Or Iron Case, Plastic caps on both ends.
    Delivery Time: 30 DAYS
    Supply Ability: 1500 tons per month
    Contact Now
    Detailed Product Description
    Material: N04400 Standard: ASTM B165
    Size: OD:3MM TO 530MM ,WT:0.2MM TO 60MM, L:MAX 50M Packing: Ply-wooden Case Or Iron Case



    ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET ASME SB165 N04400 PIPE​



    Monel Alloy 400



    Common Trade Names:

    Monel 400, Alloy 400; Nickel 400; Nickelvac 400; Nicorros 400.

    Monel Alloy nickel-copper alloy 400 (UNS N04400; W.Nr. 2.4360 and 2.4361) is a solid-solution alloy that can be hardened only by cold working. It has high strength and toughness over a wide

    temperature range and excellent resistance to many corrosive environments.

    Alloy 400 is widely used in many fields, especially marine and chemical processing. Typical applications

    are valves and pumps; pump and propeller shafts; marine fixtures and fasteners; electrical and electronic

    components; springs; chemical processing equipment; gasoline and fresh water tanks; crude petroleum

    stills, process vessels and piping; boiler feed water heaters and other heat exchangers; and deaerating

    heaters.



    Specifications


    MONEL alloy 400 is designated as UNS N04400 and Werkstoff Nr. 2.4360 and 2.4361. It is listed in NACE

    MR-01-75 for oil and gas service.

    Plate, Sheet, and Strip: - BS3072NA13 (Sheet and Plate), BS3073NA13 (Strip), ASTM B 127, ASME SB

    127 (Plate,Sheet, and Strip), SAE AMS 4544 (Sheet, Strip, and Plate),
    DIN 17750 (Plate, Strip and Sheet), QQ-N-281 (Plate, Sheet, Strip, Bar, Rod, Wire, and Forgings)

    Bar, Rod, Wire, and Forgings - BS3075NA13 (Wire), BS3076NA13 (Bar), ASTM B 164 (Rod, Bar, and

    Wire), ASTM B 564 (Forgings), ASME SB 164 (Rod, Bar, and Wire), ASME SB 564 (Forgings), AECMA

    PrEN 2305 (Wire for Rivets), SAE AMS 4675 (Bars and Forgings),SAE AMS 4730 (Wire), SAE AMS 4731

    (Wire and Ribbon), DIN 17752 (Rod and Bar), DIN 17753 (Wire), DIN 17754 (Forgings), VdTÜV 263

    (Sheet, Plate, Bar, and Tubing), QQ-N-281 (Plate, Sheet, Strip, Bar, Rod, Wire, and Forgings)

    Pipe and Tube - BS3074NA13 (Tube), ASTM B 163 (Condenser and Heat Exchanger Tube), ASTM B 165

    (Seamless Pipe and Tube), ASTM B 725 (Welded Pipe), ASTM B 730 (Welded Tube), ASTM B 751

    (Welded Tube), ASTM B 775 (Welded Pipe), ASTM B 829 (Seamless Pipe and Tube), ASME SB 163

    (Condenser and Heat Exchanger Tubes), ASME SB 165 (Seamless Pipe and Tube), ASME SB 725

    (Welded Pipe), ASME SB 730 (Welded Tube), ASME SB 751 (Seamless and Welded Tube), ASME SB 775

    (Seamless and Welded Pipe), ASME SB 829 (Seamless Pipe and Tube), SAE AMS 4574 (Seamless

    Tubing), DIN 17751 (Pipe and Tube), VdTÜV 263 (Sheet, Plate, Bar, and Tubing),

    Welding Products - MONEL Filler Metal 60-AWS A5.14/ERNiCu-7; MONEL Welding Electrode 190-AWS

    A5.11/ENiCu-7.

    Other Products - ASTM B 366, ASME SB 366 (Welded Fittings), SAE AMS 7233 (Rivets), DIN 17743

    (Chemical Composition)



    Chemical Composition

    Nickel (plus Cobalt) .....................................................63.0 min.

    Carbon..........................................................................0.3 max.

    Manganese ...................................................................2.0 max.

    Iron................................................................................2.5 max.

    Sulfur ........................................................................0.024 max.

    Silicon ...........................................................................0.5 max.

    Copper ......................................................................28.0 - 34.0



    ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE

    ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE

    ASTM B165 MONEL 400 SEAMLESS PIPE 273X9.27X5000-5800MM 100% UT & ET  ASME SB165 N04400 PIPE
