ASTM A789 ASMESA789 SUPER DUPLEX STEEL SEAMLESS TUBE MATERIAL S31803, S32205, S32750, S32760, S31254 For Heat Exchanger

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015, IEI
Model Number:	OD19.05WT2.11LENGTH13600MM

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	NEGOTIABLE
Packaging Details:	Wooden Box package
Delivery Time:	30 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	1500 TONS PER MONTH

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Material:	S31803, S32205, S32750, S32760, S31254	Size:	OD:3MM TO 530MM ,WT:0.2MM TO 60MM, L:MAX 50M
Standard:	ASTM A789, ASME SA789	NDT TEST:	Eddy Current Test, Hydrostatic Test, UT, IGC, Grain Size Test , ...
Thickness:	Minimum Wall Thickness	Package:	Plywooden Box Package
Highlight:	duplex steel pipes , welded steel pipe

ASTM A789 ASMESA789 DUPLEX STEEL SEAMLESS TUBE MATERIAL S31803, S32205, S32750, S32760, S31254 FOR HEAT EXCHANGER

YUHONG GROUP deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) seamless and welded pipe and tube already more than 25 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 85 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.

Duplex Stainless Steel have a structure that contains both ferrite and austenite. Duplex alloys have higher strength and better stress corrosion cracking resistance than most austenitic alloys and greater toughness than ferritic alloys, especially at low temperatures. The corrosion resistance of duplex alloys depends primarily on their composition, especially the amount of chromium, molybdenum, and nitrogen they contain.

Standard: ASTM/ASME A/SA789, A/SA790, A/SA928, DIN17456/17458, EN10216-5. After negotiation, we can supply pipe with customer's special requirement.

Material Grade: Chemical Composition

UNS	EN	DIN	C %	Cr%	Ni%	Mo%	N%	Other %
S31803	1.4462	X2CrNiMoN22-5-3	0.030max	21.0-23.0	4.5-6.5	2.5-3.5	0.08-0.20	/
S32205	1.4462	X2CrNiMoN22-5-3	0.030max	22.0-23.0	4.5-6.5	3.0-3.5	0.14-0.20	/
S32101	1.4162		0.040max	21.0-22.0	1.35-1.70	0.10-0.80	0.20-0.25	Cu 0.10-0.80
S32304			0.030max	21.5-24.5	3.0-5.5	0.05-0.60	0.15-0.20	Cu 0.05-0.60
S32750	1.4410	X2CrNiMoN25-7-4	0.030max	24.0-26.0	6.0-8.0	3.0-5.0	0.24-0.32	Cu 0.50max
S32760			0.050max	24.0-26.0	6.0-8.0	3.0-4.0	0.20-0.30	Cu 0.50-1.00

Mechanical Property:

UNS	Tensile Strength Min, Mpa	Yield Strength Min, Mpa	Elongation in 2 in Or 50mm Min, %	Hardness Max, HRC
S31803	620	450	25	30
S32205	655	485	25	30
S32101	700	530	30	30
S32304	690	450	25	30
S32750	800	550	15	32
S32760	750	550	25	32

Heat Treatment

UNS Designation	Temperature	Quench
S31803	1870-2010 °F [1020-1100°C]	Rapid cooling in air or water
S32205	1870-2010 °F [1020-1100°C]	Rapid cooling in air or water
S31500	1800-1900 °F [980-1040°C]	Rapid cooling in air or water
S32550	1900 °F [1040°C] min.	Rapid cooling in air or water
S31200	1920-2010 °F [1050-1100°C]	Rapid cooling in water
S31260	1870-2010 °F [1020-1100°C]	Rapid cooling in water
S32001	1800-1950 °F [982-1066°C]	Rapid cooling in air or water
S32003	1850-2050 °F [1010-1120°C]	Rapid cooling in air or water
S32101	1870 °F min	Quenched in water or Rapidly cooling in other means
S32202	1870-1975 °F [1020-1080°C]	Rapid cooling in air or water
S32506	1870-2050 °F [1020-1120°C]	Rapid cooling in air or water
S32304	1700-1920 °F [925-1050°C]	Rapid cooling in air or water
S32750	1880-2060 °F [1025-1125°C]	Rapid cooling in air or water
S32760	2010-2085 °F [1100-1140°C]	Rapid cooling in air or water
S32950	1820-1880 °F [990-1025°C]	Rapid cooling in water
S32520	1975-2050 °F [1080-1120°C]	Rapid cooling in air or water

Duplex Steel Seamless Tube Features:

1.Superior resistance to general and local corrosion, especially to stress corrosion, pitting corrosion, crevice corrosion, corrosion fatigue and abrasion & corrosion.
2.Good weldability
3.Good mechanical properties
4.Excellent intergranular corrosion resistance
5.High cost-effectiveness, long life time

Application :

Widely used in petroleum, chemical, medical, food, light industry, home decoration, mechanical instrumentation, and other industrial transmission pipelines and mechanical structural components, etc.
