Carbon Steel Seamless Tube A179 A192 A210 Straight Tube / U Bend Tube / Coil Tube Type,6M/PC,12M/PC for Heat Exchanger

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG HOLDING GROUP
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	A179 A192 A210

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case
Delivery Time:	10-15 DAYS
Payment Terms:	L/C, T/T
Supply Ability:	ACCORDING TO CUSTOMER'S REQUEST

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Spec.:

A179 A192 A210

Type:

Straight Tube , U Bend Tube, Coil Tube

Surface:

Oild Painting

Package:

PLY-WOODEN CASE

Highlight:

seamless stainless steel tube

seamless boiler tubes

Carbon Steel Seamless Tube A179 A192 A210 Straight Tube / U Bend Tube / Coil Tube Type,6M/PC,12M/PC for Heat Exchanger

YUHONG HOLDING GROUP deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) seamless and welded pipe and tube already more than 25 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 45 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia,Korea, Singapore, Austrial, Poland, France , ....And our group branch company and factory have been already approved by :ABS, DNV, GL, BV, PED 97/23/EC, AD2000-WO, GOST9941-81, CCS, TS, CNNC, ISO9001-2008, ISO 14001-2004.

Specifications

Dimensions	All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.

Sizes	This specifification covers tubes 1/8 to 3 in. [3.2 to 76.2mm], inclusive, in outside diameter.

Manufacture	Tubes shall be made by the seamless process and shall be cold drawn.

Heat Treatment	Tubes shall be heat treated after the fifinal cold draw pass at a temperature of 1200°F [650°C] or higher.

Length	As required by clients

Wall Thickness	BWG required by clients

Surface Condition	Finished tubes shall be free of scale. A slight amount of oxidation will not be considered as scale
Bending Radius	From 1.5OD(Outside Diameter) To 1500mm, ≤1.5OD,necessary To agree precision of geometrics
Straight Tubes	max length 35000mm

Test Required:

Corrosion Test
Chemical Analysis
Mechanical Tests: Flattening test, Flaring test, Flange test, Hardness Test and Hydrostatic test
Reverse-bend and Re. flat tests
Eddy Current Testing
Hydrostatic Testing
Air Under Pressure Test
Visual Inspection
Chemical Composition

Chemical Composition	C	Mn	P≤	S≤	Si≤
Chemical Composition	0.06-0.18	0.27-0.63	0.035	0.035	0.25

Mechanical Property

Steel Grade	Yield Strength (Mpa)	Tensile Strength (Mpa)	Elongation (%)	Hardness
ASTM A179	≥180	≥325	≥35	≤72 HRB

Applications Industry

Pharmaceutical Equipment
Off-Shore Oil Drilling Companies
Chemical Equipment
Power Generation
Sea Water Equipment
Petrochemicals
Heat Exchangers / Condensers / Boiler
Gas Processing
Specialty Chemicals
Pulp and Paper Industry
