DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675

DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675

    • DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675
    • DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675
    • DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675
    • DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675
    • DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675
  • DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675

    Product Details:

    Place of Origin: CHINA
    Brand Name: YUHONG
    Certification: ABS,GL,DNV,NK,PED,AD2000,GOST
    Model Number: UNS N10675

    Payment & Shipping Terms:

    Minimum Order Quantity: 10pcs
    Price: Discussion
    Packaging Details: according to client requirements/ wooden case packing....
    Delivery Time: 30 days
    Payment Terms: T/T, L/C at sight
    Supply Ability: according to client requirments
    Contact Now
    Detailed Product Description
    Material Grade: UNS N10675 Standard: ASTM B366
    Certificate: ISO9001 Third Party Inspection: BV,SGS,ASP
    DNT: ET,UT,PT,HT Surface: Pickling

    Butt Weld Fittings, Lap joint Stub end, ASTM B366 UNS N10675, DN50 SCH10S 150#, B16.9





    YUHONG GROUP is professional for Duplex and Suer Duplex pipe/tube/fitting/flange for many projects . Every we export around 4M usd of duplex and suer duplex fitting and flange for more than 30 countries .



    Stub Ends are fittings used in place of welded flanges where rotating back up flanges are desired. They are also called Lap Joints and Vanstone Flared Laps. A rotating back up flange seats itself against the back surface of the Stub End. When bolts are added, the clamping action of the bolts presses the rotating back up flange against the back of the Stub End. The gasket surface of the Stub End then presses against a gasket and another gasket surface providing joints like standard flange joints. The seal is made by the gasket surface of the stub end alone, the flange only provides the clamping pressure on the joint.
    Our high quality stub ends (Butt weld fittings) are tested and verified for durability, accuracy and precision. The stub ends are manufactured in all standard dimensions. The stub ends are provided with a standard weld bevel and can be available in squared, flanged, victaulic and threaded ends. We offer stub ends at highly competitive prices.



    Material: WP304, WP304L, WP316, 321, 321H, UNS S31803, UNS S32750, N06600, N10675.
    Size: 1/2" - 24"
    Types:
    Seamless / ERW / Welded / Fabricated /Forged
    Manufacturing standard: ASME/ANSI B16.9, JIS, DIN, EN, API 5L, etc.
    Surface treatment: Shot blasted





    Stub ends ANSI B 16.9

    Stub Ends are fittings used in place of welded flanges where rotating back up flanges are desired. They are also called Lap Joints and Vanstone Flared Laps. A rotating back up flange seats itself against the back surface of the Stub End. When bolts are added, the clamping action of the bolts presses the rotating back up flange against the back of the Stub End. The gasket surface of the Stub End then presses against a gasket and another gasket surface providing joints like standard flange joints. The seal is made by the gasket surface of the stub end alone, the flange only provides the clamping pressure on the joint. Our high quality stub ends (Butt weld fittings) are tested and verified for durability, accuracy and precision. The stub ends are manufactured in all standard dimensions. The stub ends are provided with a standard weld bevel and can be available in squared, flanged, victaulic and threaded ends. We offer stub ends at highly competitive prices.

    Butt Weld Fittings,Stub Ends,A234-WP11 A234-WP22 A234-WP5, A234-WP9, A234-WP91,Type A,Type B,Type C,Type D,B16.9



    Prosaic Steel & Alloys manufactures a wide range of stub ends (pipefitting) made of materials - exotic metals, nickel, cupro-nickel, Stainless Steel etc., of various grades. Prosaic Steel & Alloys manufactures & supplies high quality stub ends (pipe fittings) that can be used for various applications. Our stub ends are tested and verified for durability, accuracy and precision.

    Prosaic Steel & Alloys manufactures seamless stub ends of long & short radius to MSS and ANSI B 16.9 standard from Schedules 10 to 160.

    Prosaic Steel & Alloys designs & manufactures subtends (pipe fitting) of special type made according to drawing on request.



    Other materials Fittings



    Seamless & Welded Butt-weld fittings in Titanium Grades 1, 2, 5, 7, 9 and 12
    Seamless & Welded Butt-weld fittings in Duplex UNS S31803 & S32205
    Seamless & Welded Butt-weld fittings in Super Duplex UNS S32750 & S32760
    Seamless & Welded Butt-weld fittings in 6 Moly UNS S31254, N08925 & N08926
    Seamless & Welded Butt-weld fittings in Copper Nickel UNS C70600 C70620 C7060X C7150 C71520 C71640



    Value Added Services

    • Hot Dip Galvanizing
    • Epoxy Coating

    Test Certificate
    Mill Test Certificate as per EN 10204 / 3.1B



    Lap Joint Stub end

    Flange lap joint in welding , steel lap joint flange for pipes and tube

    DN50 SCH10S 150# Butt Weld Fittings Lap Joint Stub End ASTM B366 UNS N10675
