ASTM B407 UNS N08810 Incoloy 800H Seamless Alloy Steel Pipe

ASTM B407 UNS N08810 Incoloy 800H Seamless Alloy Steel Pipe

ASTM B407 UNS N08810 Incoloy 800H Seamless Alloy Steel Pipe
video
ASTM B407 UNS N08810 Incoloy 800H Seamless Alloy Steel Pipe
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: DIN 2391 ST52 EN 10305-1 High Precision Cold Drawn Steel Tube
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
STANDARD: JIS, AiSi, ASTM, GB, DIN, EN SPECIFICATION: B407 UNS N08810 Incoloy 800H Nickel Alloy Steel Tube
Package: Standard Seaworthy Package Technique: Hot/cold-drawn-rolling
Surface Condition: Bright/Acid White Shape: Round/Square/Rectangular/Oval.
Application: Marine & Offshore, Oil And Gas,boiler,heat Exchanger,handrail
High Light:

ASTM B407 seamless alloy steel pipe

,

Incoloy 800H seamless alloy steel pipe

,

ASTM B407 alloy steel seamless pipe

B407 UNS N08810 Incoloy 800H nickel alloy steel tube



We are one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years, we have accumulated a great many clients all around the world and Yuhong products also won the great praise among the customers.



ASTM B407 Incoloy 800H tube is supplied either in the form of cold worked or hot finished manner. Aside from conforming to the chemistry requirements of the said specification ASTM B407 Incoloy 800H tube, is to be heat treated at determined annealing temperatures.



The characteristics of Incoloy 800H



High temperature strength

High creep rupture strength

Resistant to oxidation and carburization in high temperature environments

Good corrosion resistance in many acidic environments

Good resistance to many sulfur-containing atmospheres





B407 Incoloy 800H tube Mechanical Properties

Alloy Tensile Stress (MPa) min Yield Stress 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
800H Psi - 75,000 , MPa - 520 Psi - 30,000 , MPa -205 30 - -



B407 Incoloy 800H tube Chemical Composition

Grade ASTM B407 Incoloy 800H
min max
C 0.05 0.1
Mn 1.5
Si 1
Al 0.15 0.6
Ti 0.15 0.6
P
S 0.015
Cr 19 23
Ni 30 35
Cu 0.75
Fe 39.5



B407 Incoloy 800H tube Physical Properties

Grade ASTM B407 Incoloy 800H
Density 7.94 g/cm3
Melting Point 1385 °C (2525 °F)



B407 Incoloy 800H tube Equivalent Grade

Grade ASTM B407 Incoloy 800H
UNS No N08810
Old British BS NA 15(H)
En X10NiCrAlTi32-20
Euronorm No 1.4958 / 1.4876
AFNOR Z8NC32-21
Japanese JIS NCF 800H
GOST ЭИ670
OR XH32T





B407 Incoloy 800H tube Application

  • Gas Processing Industries
  • Petrochemical Industries
  • Power Generation Industries
  • Food Processing Industries
  • Chemical Industries
  • Oil & Gas Industries
  • Fertilizers Industries
  • Sugar Industries



Alloys 800H/HT are used in a variety of applications involving exposure to corrosive environments and high temperatures such as heat treating equipment, chemical and petrochemical processing, nuclear power plants and the paper pulp industry. Heat-treating equipment such as baskets, trays, and fixtures employ Incoloy 800H/HT. Chemical and petrochemical processing industries use the alloys for heat exchangers and other piping systems in nitric acid media especially where resistance to chloride stress-corrosion cracking is required. Power plants use them for super-heater and re-heater tubing.





ASTM B407 UNS N08810 Incoloy 800H Seamless Alloy Steel Pipe 0
