ASTM A403 WP304H Stainless Steel 90 Deg. LR Elbow ASME B16.9 Buttweld Fitting

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A403 WP304H Stainless Steel 90deg. Elbow

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Packaging Details:	PLY-WOODEN CASE OR PALLET
Delivery Time:	7 DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Stainless Steel Buttweld Elbow	Dimension Standard:	ANSI B16.9, MSS SP 43 , EN10253-4
Specification:	ASTM A403, ASME SA403	Material:	WP304, WP304L , WP304H, 1.4301, 1.4306, 1.4307, SUS304, SUSU304L
O.D.:	1/2" NB - 48" NB	W.T.:	Schedule 10s - Schedule XXS
Type:	45/90/180 Degree Elbow	Radius:	SR, LR, R=1D, 2D, 3D, 5D, Or Custom
Form:	Elbow, Tee, Reducer, Nipple
Highlight:	180 Degree Butt Weld Elbow , 90 Degree Butt Weld Elbow , WP304H Butt Weld Fittings

ASTM A403 WP304H 90 DEG. LR Buttweld Elbow Stainless Steel Pipe Fittings

YUHONG is engaged in supplying a wide range of Buttweld Fitting that is available in varied types such as L/R & S/R elbow, tee, concentric and eccentric reducers, reducing elbow & tee, cross and caps. The regular material grades include carbon steel, stainless steel, duplex steel, nickel/alloy steel. According to different using environment, these can be found in several industries such as oil & gas, automobile, acid & chemical, pharmaceutical and cement industries.

Standard	ASTM/ASME SA403, ASTM/ASME SB366, ASTM/ASME SA234
Material	Nickel Alloy ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 ) Stainless Steel ASTM / ASME SA 403 GR WP "S" / "W" / " WX" 304 , 304L, 304H, 304N, 304LN, 309, 310H, 316, 316H, 317, 317L, 321, 321H, 347, 347 H. Duplex Steel ASTM / ASME SA 815 UNS NO.S 31803, S 32205, S 32550, S 32750, S 32760. Carbon Steel ASTM / ASME A 234 WPB, WPC ASTM / ASME A 860 WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. Alloy Steel ASTM / ASME A 234 WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 23, WP 91
Form	Elbows in Long & Short Radius in 45 deg, 90 deg, 180 deg. Return Bend, U Bend, Long Radius Bend. Equal, Unequal Tee & Barred Tee. Eccentric Reducer & Concentric Reducer. Caps & Crosses. Long & Short Stub End. Swage Nipple & Barrel Nipple Laterals
Size	OD: 1/2" NB - 48" NB, WT: Schedule 10s - Schedule XXS

Butt Weld Elbow (90°)

Pipe fittings are essential components in piping systems.

Ebow refers to a segment of pipe that features a sharp bend. These fittings are widely utilized across various industries for pipe installation.
Butt Weld Elbow SR ASTM A403 WP304H Steel Pipe Fittings 3 Often employed in pressurized applications,pipe elbows come in different shapes and sizes to suit diverse needs.

They are designed to connect two lengths of pipe or tubing, facilitating directional changes.

YUHONG manufactures seamless & welded elbows (Buttweld pipe fitting) of types 90° Elbows, 90° Elbow, 45° Elbows, 180° Elbow to ANSI/ASME B16.9

Butt Weld Elbow (45°)
Owing to offer quality products, we are involved in making of elbow 45 degree for our customers. These pipe fittings offer amazing functionality. Stainless steel, alloy steel, nickel alloys are used for crafting these pipe fittings. Our Elbow (45°) pipe fitting is offered at market leading rates.

Butt Weld Elbow (180°)
We have earned prominent name in designing of Elbow (180°) fitting. These pipe fittings serve wide range of functionalities in outstanding way. The Elbow 180 degree is crafted with great precision by our experienced staff. We provide best rates for elbow 180 degree.
