ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser

ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser

  • ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser
  • ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser
  • ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser
  • ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser
ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG SPECIAL STEEL
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASME SB111/ASTM B111 C44300
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle With Plastic Cap
Delivery Time: Depends on quantity
Payment Terms: T/T, L/C
Supply Ability: ACCORDING TO CLIENT'S REQUIREMENT
Contact Now
Detailed Product Description
Product Name: Cooper Seamless Tube Standard: ASME SB111/ASTM B111
Material: C44300 Test: ET, HT, Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing.
Finish: Cold Drawn Surface: Polished
Shape: Round Application: Boiler Pipe, Hydraulic/Automobile Pipe/ Heat Exchanger Tube
High Light:

C44300 Brass Air Cooling Tube

,

ASTM B111 Air Cooling Tube

,

ASTM B111 Condenser Tube

ASTM B111 C44300 Cooper SEAMLESS TUBE ( HEAT EXCHANGER, CONDENSER , AIR COOLING)



Description:

Standard: ASTM B111/ ASME SB111 Material: C44300
Testing: ET, HT, Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing. Application: Boiler Pipe, Hydraulic/Automobile Pipe,
Surface: Polished Shape: Round Pipe
High Light:

C44300 Seamless Boiler Tubes

,

Cold Finished Seamless Boiler Tubes

,

ASME SB111 Seamless Boiler Tubes



  ASTM B111 ASME SB 111 C44300 Admiralty Brass is ideal for heat exchanger tubes. Normally made to order to meet engineering requirements, you will find this alloy often times used in oil and gas applications that also require its non corrosive properties. C44300 and C68700 have good corrosion resistance. C44300 Admiralty Brass Seamless Tubes Tensile strength minimum in 310Mpa, Yield Strength minimum in 105Mpa.



COUNTRY STANDARD NAME
ASTM ASTM B111 Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock
GB/T GB/T8890 Seamless Copper Alloy Heat Exchanger Tubes
BS BS2871 Copper and Copper Alloys Tubes
JIS JIS H3300 Copper and Copper Alloy-Seamless Pipes and Tubes
DIN DIN1785 Wrought Copper and Copper Alloy Tubes for Condensers and Heat Exchangers



ASTM B111 / ASME SB 111 C44300 Admiralty Brass Chemical Composition

Elements Composition, %
Cu, incl. Ag 70.0-73.0
Sn 0.9-1.2
Al
Ni, incl. Co
Pb 0.06 max
Fe 0.07 max
Zn Balance
Mn
As 0.02-0.06
Sb
P
Cr
Other named elements


ASTM B111 / ASME SB 111 C44300 Admiralty Brass Mechanical Properties

Properties Measurement
Yield strength 105 MPa
Melting point 899 ~ 938 °C
Tensile strength 310 MPa
Thermal conductivity 109 W/m-K @ 20.0 °C
Density 8.53 g/cc
Heat capacity 0.09 cal/g-°C @ 20ºC
CTE linear strength 20.2 10-6/°C @ 20.0 – 300 °C



ASTM B111 / ASME SB 111 C44300 Admiralty Brass Physical Properties

Copper or Copper Alloy UNS No. Melting Point Density Coefficients of Linear Thermal Expansion Specific Heat Capacity Thermal Conductivity
°C °F lb/in3 g/cm3 1×10-6/°C @ 20.0 – 30.0 °C 1×10-6/°F @ 70.0 – 570 °F cal/g-°C, 20 °C BTU/lb-°F @ 70°F W/m-K, 20 °C BTU/ft2/ft/h/°F @ 70°F
C44300 2140 – 2260 2010-2100 0.308 8.53 16.2 9 0.09 0.09 29 17



Typical Application of ASTM B111 ASME SB 111 C44300 Admiralty Brass

1. Industrial: Evaporator Tubing, Heat Exchanger Tubing, Condenser Tube Plates, Distiller Tubes, Oil Well Pump Liner, Ferrules, Bourdon Tubes, Condenser Tubes

2. C44300 admiralty brass tubes and C70600,C71500 copper nickel tubes are widely used in “Industrial Steam Turbine Condensers”

2. Plumbing: Strainers



SB111 C44300 material has the following benefits:

  • Durability – The structure and chemical composition of an SB111 C44300 makes it durable. Its products can last up to 10 years, depending on where you are using it and the frequency of use.
  • Cost-effective – The overall value of installing, functioning and maintaining products of this material is relatively low. You, therefore, get quality by selecting this material to manufacture your products.
  • Versatile usage – You can manufacture different products using this material. For instance, you can make pipes and tubes for a variety of usage.



Test:

  • Pitting Tests
  • Intergranular Corrosion Test
  • Chemical Analysis
  • Hardness Test



ASME SB111/ASTM B111 C44300 Cooper seamless Tube Applied For Condenser 0
