API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube

API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube

  • API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube
  • API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube
  • API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube
  • API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube
API Seamless Astm A270 Tp316l Stainless Steel Sanitary Tube
Product Details:
Place of Origin: CHINA
Brand Name: YuHong
Certification: API , ABS, DNV, GL , LR, NK
Model Number: TP304 TP304L TP316 TP316L
Payment & Shipping Terms:
Minimum Order Quantity: 1000KG
Price: Negotiable
Packaging Details: Ply-wooden Case Or Iron Case
Delivery Time: 7DAYS TO 60 DAYS
Payment Terms: L/C, T/T
Supply Ability: ACCORDING TO CUSTOMER'S REQUEST
Contact Now
Detailed Product Description
Standard: ASTM A270 ,3A, ISO11850 Material Grade: TP304/304L, TP316/316L
Packing: Plywood\wooden Pallets Type: Welded,Seamless
High Light:

astm a270 stainless steel sanitary tube

,

tp316l stainless steel sanitary tube

,

api stainless steel seamless pipe

ASTM A270 TP316L Stainless Steel Seamless Tube /Sanitary Tube



ASTM A270 TP316L sanitary stainless pipe usually refers to the small pipe diameters, normally from 1/2” to 2 1/2”, thickness from 0.049 inch (1.24mm) to 0.15 inch (3.81mm). The maximum outer diameter of ASTM A270 TP316L tubing is 12 inch (316L.8 mm). ASTM A270 TP316L tubing using inch pound as the standard unit of measure. ASTM A270 TP316L Tube wall thickness tolerance shall not vary more than 12.5%.





ASTM A270 TP316L STAINLESS STEEL SANITARY TUBE SPECIFICATION

ASTM A270 TP316L Sanitary Tubing Type
Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing
ASTM A270 TP316L Sanitary Tube OD. 1/2”
ASTM A270 TP316L Sanitary Tube Wall 16 Gauge (0.065”)
ASTM A270 TP316L Sanitary Tube Length 20′
ASTM A270 TP316L Sanitary Tube OD Tolerance +/-0.005” / +/-0.13MM
ASTM A270 TP316L Sanitary Tube WT Tolerance +/-10%
ASTM A270 TP316L Sanitary Tube Length Tolerance +1/8” / +3.18MM
ASTM A270 TP316L Sanitary Tube Material SS 304, SS 304L,SS 316,SS 316L
ASTM A270 TP316L Sanitary Tubing Standard 3A / ASTM A270 / A270M
ASTM A270 TP316L Sanitary Tubing Finish 2B MIll Finish , No.4 finish, BA Finish, 400 Grit Finish, 550 Grit Finish, 600 Grit Finish
ASTM A270 TP316L Sanitary Tubing Polish Mechanical Polished
ASTM A270 TP316L Sanitary Tubing Type Seamless
ASTM A270 TP316L Sanitary Tubing Certification 3A – Food / Dairy Grade
ASTM A270 TP316L Sanitary Tubing Mill Test Certificate EN10204 3.1
ASTM A270 TP316L Product ASTM A270 316L Sanitary Tubing, ASTM A270 SS316L Seamless Sanitary Tubes, ASTM A270 Type 316L Tubing, ASTM A270 TP316L Welded Sanitary Tubing, ASTM A270 316L Welded Sanitary Tubes, ASTM A270 TP316L Stainless Steel Sanitary Tubing
ASTM A270 TP316L Sanitary Tubing Packing Sleeved, Ends Capped, Wooden Boxe



ASTM A270 TP316L sanitary stainless steel pipe shall be noted below points during manufacturing processes:

1) ASTM A270 TP316L Seamless steel pipe should not contains any kind of welding processing.
2) ASTM A270 TP316L Welded steel pipe applied in automatic welding processing, but should not use metal materials as filler.
3) ASTM A270 TP316L Heavily cold worked (HCW) tubes shall be manufactured by cold working of not less than 35% reduction of thickness of both wall and weld to a welded pipe prior to the final anneal. Filler materials shall be noted added during welding process. The weld shall be 100% radio graphically inspected in accordance with ASME boiler and pressure vessel standards specification.
4) ASTM A270 TP316L Sanitary pipe could be furnished with hot finished or cold finished at Manufacture’s option.

Hot-treatment methods for ASTM A270 TP316L stainless tube

All materials should supply after hot-treatment. Except the for duplex stainless steel materials S31803, S32003, S320205, S32750, N08926 and N08367, in these cases it shall consist of heating the material to a minimum temperature of 1900 ℉ (1040 ℃) and quenching in water or rapid cooling by other means.

ASTM A270 TP316L Sanitary Tubing Surface Requirements

Surface of rolled products: No need extra polishing or smooth treatment.
Mechanical polished surface: Purchasers according the same numbering abrasive (grinding stuff) to polish the products get the required products’ surface.
Electrolytic polishing of the surface: Before this processing, manufacturer could use other ways to polish products.
The maximum average of roughness: Customers could specify the maximum roughness of internal surface, external surface and both surface.
Normally surface treatment: Internal, External, SF4, SF3, etc.



ASTM A270 Seamless TP316L Stainless Steel Sanitary Tube 0
