ASTM A213 TP316L Stainless Steel Seamless Tube with High Temperature Resistance and Corrosion Resistant Cold Rolled Precision

ASTM A213 TP316L Stainless Steel Seamless Tube with High Temperature Resistance and Corrosion Resistant Cold Rolled Precision

ASTM A213 TP316L Stainless Steel Seamless Tube with High Temperature Resistance and Corrosion Resistant Cold Rolled Precision
video
ASTM A213 TP316L Stainless Steel Seamless Tube with High Temperature Resistance and Corrosion Resistant Cold Rolled Precision
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A213 TP316L
Payment & Shipping Terms:
Minimum Order Quantity: 100 KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 20-80 days
Payment Terms: T/T,L/C
Supply Ability: 1500 Tons Per Month
Contact Now
All Products
Stainless Steel Seamless Pipe (308)
Stainless Steel Seamless Tube (297)
Duplex Stainless Steel Pipe (132)
Duplex Stainless Steel Tube (33)
Needle Tube (134)
Fin Tube (672)
Heat Exchanger (20)
Heat Exchanger Tube (443)
Heat Exchanger Tube Bundle (40)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (37)
Air Cooler (9)
Pressure Vessel (4)
Stainless Steel Welded Pipe (58)
Stainless Steel Welded Tube (120)
Nickel Alloy Pipe (266)
Nickel Alloy Tube (92)
Copper Alloy Tube (240)
Alloy Steel Tube (204)
Titanium Tube (15)
Bright Annealed Tube (155)
Boiler Tube (151)
Steel Fitting (826)
Steel Flange (615)
Others (401)
Cladding Parts (7)
Detailed Product Description
Application: Construction,Decoration,Industry,boiler,Chemical Standard: GB,DIN,ASTM,JIS,AISI
Steel Grade: 300 Series,304 304L 316 316L 310S 321 Type: Seamless,Welded
Thickness: 1.24mm-3.81mm Length: 3000mm~6000mm,Customer Request,18000max.
Outer Diameter: 1/2"-8", Max 304.8mm Technique: Cold Rolled Hot Rolled,Cold Drawn,welded,seamless
Surface: Pickled Grade: 304L 316 316L 310s 321 321H 347 347H
Caps: With Plastic Caps At Both Ends Dnt: ET,UT,PT,HT
Materialrd: Ferritic And Martensitic Stainless Steel Ndt: ET, HT , UT, PT
Outside Diameter: 6-630mm Price Term: CIF CFR FOB EX-WORK
Products: Stainless Steel Flange Schedule: SCH5-XXS
Secondary Or Not: Non-secondary Temperature Resistance: High
Test: NDT Eddy Current Or Hydraulic Test Use: Heat Exchanger
Welding Type: Seamless
Highlight:

ASTM A213 Seamless Ss Tubing

,

Seamless ASTM A213 Tubing

,

TP316L Seamless Ss Tubing

ASTM A213 TP316L Stainless Steel Seamless Tube
Yuhong is a leading stainless steel pipe supplier with over 20 years of industry experience. We provide comprehensive quality verification through our expert team and stock both welded and seamless stainless steel tubing in standard industry sizes. Our products have earned global recognition and customer satisfaction.
A213 316L Stainless Steel Composition
316L is the low carbon variant of 316 stainless steel, with carbon content not exceeding 0.035% and molybdenum content ranging from 2.0-3.0%. This composition provides exceptional corrosion resistance in high acid environments. In Europe, this grade is designated as 1.4404, with minimal differences in chemical composition and mechanical properties.
Product Specifications
ASTM A213 TP316L pipe is available in diameters from ½" to 100". ERW pipe and cold drawn seamless pipe typically have an OD of 24 inches, while electrofusion welded 316L stainless steel pipe ranges from 6 inches to 100 inches. Square tubes are used for structural and high-pressure applications like hydraulic systems, while rectangular tubes complement square tube applications. Seamless tubing is ideal for sensitive and precision applications.
Available Types
We offer 316L stainless steel pipe in Electrofusion Welded (EFW), Seamless, and Welded Pipe types, all manufactured to international standards with comprehensive quality testing.
ASTM A213 316L Stainless Steel Chemical Composition
Grade C Mn P S Si Ni Cr Mo N
316L 0.035 2.00 0.045 0.030 1.0 10-14 16-18 2-3
1.4404 0.03 2.00 0.040 0.015 1.0 10-13 16.5-18.5 2-2.5 0.11
ASTM A213 316L Stainless Steel Mechanical Properties
Grade Tensile Strength (MPa) Yield Point (MPa) Elongation (%) Elongation (%)
316L 485 170 35 25
1.4404 490-690 190 40 30
316L Stainless Steel Features
  • Molybdenum-containing austenitic stainless steel with superior corrosion resistance
  • Enhanced resistance to general corrosion, pitting corrosion, and crevice corrosion compared to 304 stainless steel
  • Higher creep, rupture stress, and tensile strength at elevated temperatures
  • Recommended temperature range: -425°F to 1,200°F (-255°C to 605°C)
  • Excellent machinability and formability typical of austenitic stainless steels
  • Commonly used in marine environments and corrosive applications
ASTM A213 Stainless Steel Tubes Outside Diameter and Wall Thickness Tolerance
OD, MM OD TOLERANCE
< 25.4 +/- 0.10
25.4 - <= 38.1 +/- 0.15
> 38.1 - < 50.8 +/- 0.20
50.8 - < 63.5 +/- 0.25
63.5 - < 76.2 +/- 0.30
76.2 - <= 101.6 +/- 0.38
> 101.6 - <= 190.5 +0.38/-0.64
> 190.5 - <= 228.6 +0.38/-1.14
ASTM A213 TP316L Stainless Steel Seamless Tube with High Temperature Resistance and Corrosion Resistant Cold Rolled Precision 0
ASTM A213 TP316L is specifically designed for heat exchangers and high-pressure pipes using 316L austenitic stainless steel. The precise chemical composition of Nickel, Chromium, and Molybdenum enables operation in highly corrosive and oxidizing environments. These tubes, with thickness ranging from 0.40mm to 12.70mm, can be manufactured through hot or cold drawn processes, with cold drawn tubing offering enhanced surface finish and superior strength.
