ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler

ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler

  • ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler
  • ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler
  • ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler
  • ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler
ASTM A210 / ASME SA210 GR.A1 GR.C Carbon Steel Seamless Tube Cold Drawn For Boiler
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG SPECIAL STEEL
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008.
Model Number: ASTM A210 Gr A1 Seamless Medium Carbon-Molybdenum Alloy Steel Boiler
Payment & Shipping Terms:
Minimum Order Quantity: 100 Kgs
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with Plastic Cap
Delivery Time: 7days
Payment Terms: L/C, T/T
Supply Ability: 1000 Ton Per Month
Contact Now
Detailed Product Description
Shape: Round Technique:: Cold Drawn
Type: Seamless, Welded Surface Treatment:: Oiled Finish
Standard: ASTM, ASTM A210-1996, ANSI A210-1996
High Light:

Carbon Steel Seamless Tube

,

ASTM A210 Seamless Tube

,

ASME SA210 Boiler Tube

ASTM A210 / ASME SA210 GR.A1 GR.C CARBON STEEL SEAMLESS TUBE COLD DRAWN FOR BOILER





The CS grade boilers are widely used in various industrial applications due to its highly unmatched properties. There are several properties exhibited by them are excellent corrosion resistance, strength resistance, crevice corrosion resistance, stress crack corrosion resistance and excellent strength. The most preferred choice CS grade for manufacturing boilers is Seamless medium carbon steel boiler 210-A1.





Standard Specification ASTM A210 / A210M, ASME SA210, A210 A1, SA210 A1
Grade Grade A-1
JIS G 3467 STFA 10
Size Range 1/2 in. to 16 in. [12.7 to 406.4mm]
Wall Thickness 1.5mm-50mm
Shape Round
Manufacturing method Hot and cold finished
Length max 25 m, Single / Double random length
Terms Mill test certificates will be issued according to EN10204.3 3.1 or 3.2
A210 GR.A1 tubes Shall be Seamless, and the testing shall be as per A 450 / A450M.
Common uses Boiler Tubes, Seamless Steel Tubes, Steel Tubes, and Superheater Tubes.





ASTM A210 / A210M Grade A-1 Chemical Compositions

Chemical Components (%)
Grade C Si Mn P S Mo Cr V
A-1 ≤0.27 ≥0.10 ≤0.93 ≤0.035 ≤0.035 / / /







ASTM A210 / A210M Grade A-1 Mechanical Properties

Mechanical Properties
Grade Tensile Yield Elongation Hardness
Strength (Mpa) Strength (Mpa) (%) (HRB)
A-1 ≥415 ≥255 ≥30 ≤79





ASTM A210 / A210M Tube Wall Thickness Tolerance

Seamless, Cold-Finished Tubes
Outside Diameter Wall thickness Tolerance %
In. (mm) Over (+) Under (-)
1 1/2" (38.1) and under 20 0
Over 1 1/2" (38.1) 22 0





The specified ASTM A210 GR.A1 Seamless Steel Tubes are designed to be used in several applications as either boiler or as superheater tubes. The ASME SA210 Gr A1 Superheater Tubes that are manufactured under this specification also covers minimum wall thickness, and tubing sizes, boiler flues including safe ends, arch as well as stay tubes. While the specification for these ASME SA210 Grade A1 Pressure Vessel Tubes takes into account both the tensile strength and hardness properties but these two properties are applicable to certain size limitations. Material used in the manufacturing of ASTM A210 Grade A1 Heat Exchanger Tubes are to be killed. The ASTM A210 Grade a1 tubes are to be produced by seamless process, which in turn are to be marked as either hot finished tubes or cold finished tubes.





Application

SA210A1 is a Seamless medium carbon steel Boiler Tube used in super heater, heat exchangers, condensers, marine application, refineries, paper pulping, petrochemical applications, pressure vessels, and general engineering applications.





Ordering Information

Orders for ASTM A210 / A210M, ASME SA210 should include the following, as required, to describe the desired material adequately:

  • Quantity (feet, meters, or number of lengths),
  • Name of material (seamless tubes),
  • Grade,
  • Manufacture (hot-finished or cold-finished),
  • Size (outside diameter and minimum wall thickness),
  • Length (specific or random),
  • Optional requirements,
  • Test report required (see section on Certification of Specification A 450/A 450M),
  • Specification designation,
  • Special requirements.
