ASME SA213 T5 Alloy Steel Seamless Tube Black Painted with High Temperature Resistance for Boiler Heat Exchanger

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASME SA213 T5

Payment & Shipping Terms:

Minimum Order Quantity:	100 KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80 days
Payment Terms:	T/T,L/C
Supply Ability:	1500 Tons Per Month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Producr Name:	трубка теплообменника; Tubo Intercambiador De Calor; أنبوب المبادل الحراري; Tube D'échangeur De Chaleur	Standard:	GB,DIN,ASTM
Application:	Boiler Pipe	Thickness:	Customizable
Technique:	Cold Rolled; Hot Rolled	Length:	Customizable
Type:	Seamless	End Type:	Plain/Bevel
Temperature Resistance:	High	Fin Material:	Aluminum,carbon Steel,stainless Steel
Third Party Inspection:	BV, SGS, IBR, ABS, LR, DNV-GL , TUV	Edge:	Mill Edge Slit Edge
Secondary Or Not:	Not Secondary	Material:	Alloy Steel
Highlight:	Alloy T5 SMLS Tube , Oil Gas SMLS Tube , Boiler Seamless Alloy Steel Tube

ASME SA213 T5 Alloy Steel Seamless Tube

We are a leading manufacturer of stainless steel, duplex, and alloy steel pipes with over 20 years of industry experience. Our Yuhong products have established a strong global customer base and received widespread recognition for quality and reliability.

Product Overview

Our product range includes seamless ferritic and austenitic steel tubes specifically designed for boilers, superheaters, and heat exchangers. These tubes are manufactured to meet grades such as T91, TP304, and others as specified in Tables 1 and 2 of the standard specification.

Tubes with "H" designation in their grade names provide enhanced creep rupture strength compared to standard grades. Standard pipe sizes range from 1/8 inch (3.2 mm) to 5 inch (127 mm) inner diameter, with wall thickness from 0.015 to 0.500 inches (0.4 to 12.7 mm). Custom sizes with average wall thickness or alternative diameters can be supplied upon request.

Chemical Composition - ASME SA213 T5

Element	Composition (%)
Carbon (C)	0.15 Max
Manganese (Mn)	0.3-0.6
Phosphorus (P)	0.025 Max
Sulfur (S)	0.025 Max
Silicon (Si)	0.5 Max
Chromium (Cr)	4.00-6.00
Molybdenum (Mo)	0.45-0.65

Alloy Steel Seamless Tubes Chemical Compositions

Grade	UNS Designation	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Chromium	Molybdenum
T5	K41545	0.15	0.30-0.60	0.025	0.025	0.50	4.00-6.00	0.45-0.65
T9	K90941	0.15	0.30-0.60	0.025	0.025	0.03	1.00-1.50	0.90-1.10
T11	K11597	0.05-0.15	0.30-0.60	0.025	0.025	0.50-1.00	1.00-1.50	0.44-0.65
T22	K21590	0.05-0.15	0.30-0.60	0.025	0.025	0.50	1.90-2.60	0.87-1.13
T91	K90901	0.07-0.14	0.30-0.60	0.02	0.010	0.20-0.50	8.0-9.5	0.85-1.05

Mechanical Properties - ASME SA213 T5

Property	Value
Density	8 g/cm³
Tensile Strength	415 MPa
Yield Strength (0.2% Offset)	205 MPa
Elongation	30%

Permissible Wall Thickness Variations

Hot Rolled Tubes - Percentage Tolerance

Outside Diameter	Wall Thickness	Tolerance
OD ≤ 101.6 mm	WT ≤ 2.4 mm	+40%/-0%
OD ≤ 101.6 mm	2.4 mm < WT ≤ 3.8 mm	+35%/-0%
OD ≤ 101.6 mm	3.8 mm < WT ≤ 4.6 mm	+33%/-0%
OD ≤ 101.6 mm	WT > 4.6 mm	+28%/-0%
OD > 101.6 mm	2.4 mm < WT ≤ 3.8 mm	+35%/-0%
OD > 101.6 mm	3.8 mm < WT ≤ 4.6 mm	+33%/-0%
OD > 101.6 mm	WT > 4.6 mm	+28%/-0%

Cold Drawn Tubes - Percentage Tolerance

Outside Diameter	Tolerance
OD ≤ 38.1 mm	+20%/-0%
OD > 38.1 mm	+22%/-0%

Hot Rolled Tubes - Dimensional Tolerance (mm)

Outside Diameter	Tolerance
OD ≤ 101.6 mm	+0.4/-0.8 mm
101.6 mm < OD ≤ 190.5 mm	+0.4/-1.2 mm
190.5 mm < OD ≤ 228.6 mm	+0.4/-1.6 mm

Cold Drawn Tubes - Dimensional Tolerance (mm)

Outside Diameter	Tolerance
OD < 25.4 mm	±0.10 mm
25.4 mm ≤ OD ≤ 38.1 mm	±0.15 mm
38.1 mm < OD < 50.8 mm	±0.20 mm
50.8 mm ≤ OD < 63.5 mm	±0.25 mm
63.5 mm ≤ OD < 76.2 mm	±0.30 mm
76.2 mm ≤ OD ≤ 101.6 mm	±0.38 mm
101.6 mm < OD ≤ 190.5 mm	+0.38/-0.64 mm
190.5 mm < OD ≤ 228.6 mm	+0.38/-1.14 mm
