ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application

ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application

  • ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application
  • ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application
  • ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application
  • ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application
ASTM B444 UNS N06625 (INCONEL 625) Nickel Alloy Seamless U Tube Cold Drawn For Marine Application
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG SPECIAL STEEL
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM B444 N06625
Payment & Shipping Terms:
Minimum Order Quantity: 300KGS
Price: NEGOTIABLE
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: Depends on quantity
Payment Terms: L/C, T/T
Supply Ability: ACCORDING TO CLIENT'S REQUIREMENT
Contact Now
Detailed Product Description
Standard: ASTM B444 Material: N06625( INCONEL 625)
Type: Seamless, Welded, Heat Exchanger Application: Heat Exchanger , Boiler , Cooling, Industry
Technique: Cold Rolled Hot Rolled, Cold Drawn Steel Grade: 300 Series, 304 316 316L 321, Etc.
High Light:

Inconel 625 U Bend Tube

,

Nickel Alloy Seamless U Tube

,

Marine Seamless U Tube

ASTM B444 Gr.2 UNS N06625 Nickel Alloy Seamless U Tube Cold Worked For Marine Applications

Yuhong Group has been operating stainless steel/duplex/nickel seamless steel pipes for more than 32 years, with annual sales of more than 80,000 tons of stainless steel/duplex/nickel seamless steel pipes.

Our customers have covered more than 65 countries around the world. Our stainless steel seamless pipes are widely used in petrochemical, chemical, mining, energy, food mills, paper mills, gas and fluid industries, etc.



Inconel 625 composite pipe is generally cold worked according to ASTM B444. Generally, this cold-worked Inconel 625 seamless pipe can be supplied in 2 conditions, grade and grade 2. ASTM B444 UNS N06625 Gr 1 pipe is supplied in the annealed condition, while Grade 2 is supplied in the solution annealed condition. Also known as UNS N06625, material 2.4856 Alloy 625 pipe has many excellent properties. Key among these properties is its corrosion resistance. Inconel 625 pipe is considered ideal for marine applications for several reasons.



The main reason is that the alloy can withstand not only high stresses in and out of water, but also stresses over a wide temperature range. Inconel 625 pipe is also capable of withstanding high acid conditions. Additionally, ASME Sb 444 UNS N06625 Alloy 625 Pipe has properties such as high tensile strength, good creep resistance, and good weldability, so these pipes can be used in nuclear foundation applications. Inconel 625 Welded Pipe is a solution strengthened superalloy for high temperature and high pressure applications. Pipes produced to the ASTM B444 UNS N06625 specification generally indicate that these pipes have a seamless construction.



Material Grade/Standard Available

Nickel Alloy Material Grade ( ASTM/ASME) Standard Available
Inconel UNS N06600 UNS N06601 UNS N06625 UNS N08800 UNS N08810 UNS N08825 ASME SB167 SB423 SB407 SB444
Monel UNS N04400 ASME SB165 SB163
Hastelloy UNS N10276 ( C 276) N06022(C 22) N06455(C 4) ASME SB626 SB622



Size Range:

Seamless Pipe OD: Φ16mm-Φ114mm; WT:1.0mm-20mm
Welded Pipe OD: Φ10mm-Φ273mm; WT:2mm-30mm



Chemical Composition & Mechanical Property

UNS Ni% Cr% Mo% Cu% Fe% TS Min,Mpa YS Min,Mpa
N04400 63 min. / / 28.0-34.0 2.50 max 483 193
N06600 72 min. 14.0-17.0 / 0.50max 6.0-10.0 552 241
N06601 58.0-63.0 21.0-25.0 / 1.0 max   552 207
N06625 58 min. 20.0-23.0 8.0-10.0 / 5.0 max 827 414
N08800 30.0-35.0 19.0-23.0 / 0.75 max 39.5min. 517 207
N08825 38.0-46.0 19.5-23.5 2.5-3.5 1.5-3.0 22.0 min. 586 241



nconel 625 pipe ASTM Specification

ASTM B 167 ASME SB 167 / ASTM B 829 ASME SB 829 / ASTM B 517 ASME SB 517

  • ASTM B705 - UNS N06625 Welded Pipe
  • ASTM B444 - UNS N06625 Cold-worked seamless pipe and tube
  • ASTM B474 - Nickel Alloy 625 Electric Fusion Welded Pipe/ EFW Pipe
AMS AMS 5581, AMS 5599, AMS 5666
Manufacturing Type Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded
Thickness Range SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS
Standard SUS, JIS, AISI, ASTM, GB, DIN, EN
Inconel 625 Pipe annealed Condition Grades

UNS N06625 cold-worked seamless pipe are furnished in :

  • ASTM B444 grade 1
  • ASTM B444 grade 2
  • ASME SB444 GR.1
    ASME SB444 GR.2
Value Added Services
  • Cutting
  • Beveling
  • Threading
  • Destructive and Non Destructive
  • Ultrasonic Testing
  • Draw & Expansion as per required Size & Length
END Plain End, Beveled End, Treaded Alloy 625 UNS N06625 Pipes
Marking
  • Specification
  • Material Grade
  • Nominal Size
  • Schedule or Wall Thickness
  • Method of Manufacturing (Seamless / Welded)
  • Heat Number
  • Manufacturer’s Name or Custom Logo - on request

Marked Pipe Sample: ASTM B444 UNS N06625 12" NB SCH 40S SEAMLESS HEAT NO. XXXX

Test Certificate
  • Manufacturer Test Certificate
  • 100% Radiography Test Report
  • DFARS compliant
  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • Fumigation Certificates
  • Raw Materials Certificate
  • Third Party Inspection Report
  • Moisture testing
  • Heat Treatment Charts
  • Surface roughness measurement
  • HS Code Commercial Invoice
  • Laboratory Test Certificate from Govt. Approved Lab
  • Form A for Generalized System of Preferences (GSP)
625 Inconel Pipe Packaging Packed in PE Fabric Bundles or ply wooden box wrapped in plastic or Standard seaworthy export packing or as per customers' request
