Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Model Number: | ASTM A312 TP310S |
| Minimum Order Quantity: | 100 KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 1500 Tons Per Month |
| Certification: | ISO, SGS, BV, ISO&SGS, ISO/CE/SGS | Steel Grade: | 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series |
|---|---|---|---|
| Type: | Seamless, Welded, Round Pipe | Standard: | ASTM, AISI, GB, DIN, JIS |
| Length: | 3000-6000mm, Customized, 1800max, 11.8m Or As Required, 8m | Thickness: | 0.4-30mm, 1.0mm, 0.6-2500mm,1-60mm, 0.6-25mm |
| Technique: | Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them | Product Name: | Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube |
| Material: | 200 Series/300 Series/400 Series, 601 625 800 825, Stainless Steel, SS 201/304/316, X5CrNi18-20/1.4301 | Outer Diameter: | 6-630mm, 6-762mm, 6-860mm, Customized |
| Grade: | 304, 304L, 316, 316L, 321, 347, 904L | Finish: | Brush Polish, Cold Drawn, Bright Annealed Or Un Annealed |
| Color: | White Silver Gold | Delivery Condition: | Soft / Hard |
| End Cut: | Plain End | Inspection: | 100% Eddy Current , Hydraulic Test |
| Invoicing: | By Actual Weight | Orignal: | Shanghai |
| Package: | Standard Export Package | Payment: | 30% TT Advance + 70% Balance |
| Pressure Rating: | 3000LBS, 6000LBS, 9000LBS | Process: | Hot Rolled |
| Product Type: | Pipe | Surface: | AP |
| Trademark: | Shengtian | Welding Line Type: | EFW |
| High Light: | TP310S Stainless Steel Seamless Pipe,PMI Stainless Steel Round Pipe,Pickled Cold Rolled Seamless Pipe |
||
Yuhong Special Steel has been engaged in seamless welded steel pipes of austenitic stainless steel and nickel alloy steel (Hastelloy, Monel, Inconel, Inconel) for more than 25 years, and sells steel pipes every year. Over 80,000 tons. Our customers cover more than 45 countries in Europe, Middle East, North and South America, South Korea, Singapore, Australia, etc.
Describe
ASTM A312 310s is a long-term material for general corrosion service and high temperature service. The composition of A312 Tp310s material includes carbon, manganese, silicon, phosphorus, sulfur and chromium and nickel. This composition enables the material to withstand strong oxidizing agents at high temperatures. However, SA 312 Tp 310s has a lower carbon content than the standard version, which increases the toughness of the pipe. In contrast, the high temperature strength of 310s stainless steel pipe products is reduced. Therefore, they are preferred in applications that operate continuously at mild to high temperatures. Due to the low carbon content, 310s stainless steel welded pipe does not experience much intergranular corrosion. Therefore, there is no localized corrosion of these pipes. Therefore, applications that require extensive welding can use this material grade. Excellent toughness and reduced corrosion make them suitable for low temperature conditions as well. But the most common application for Seamless 310 is general corrosion service.
The 310s material also has a minimum yield strength of 205 MPa and a minimum tensile strength of 525 MPa. This also allows the material to be used under high pressure. The combination of all these properties enables the material to be used in burners, annealing caps, stills, combustion chambers, lead cans and radiant tubes under these respective harsh conditions.
SS 310s tubing is highly ductile and can be shaped as required. Cold drawn tubing is easy to form, but SS 310s Erw tubing is resistance welded and stronger. The different production mechanisms used with this material grade have advantages. Our SS 310s round tube is the most common, we offer other shapes such as SS 310s square tube. If you have any questions, please contact us.
| ASTM Specification Format | ASTM A312 / ASTM SA312 |
| Dimensional ASTM / ASME Standard | ANSI/ASME B36.19M, ANSI/ASME B36.10M |
| Shapes and Types we produce | Round, Honed, Rectangle, Hydraulic, Hex, Square |
| Manufacturing Different Types | Welded, 100% X Ray Welded, Seamless, CDW, Fabricated, ERW |
| Pipe End Forming | Beveled One End, Plain One End, Bevel small end, Treaded On End, Treaded Both Ends, Bevel both ends, Plain Both Ends, Beveled end, Bevel large end, Bevel one end |
| TDC (Technical Delivery Conditions) | Polished, Annealed and Pickled, Cold Drawn, Bright Annealed |
| Id and Od Finish Types | 2B, No.4, No.1, No.8 Mirror Finish or custom Finish as per customer Requirements |
| Pipe Wall Thickness Tolerance Chart | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Other Value Added Facilities | Machining, Customer Tagging/ Marking, Export Documentation, Grooving, Threading, Beveling, Non Destructive, Polishing, Threading, Cutting, Color Coding, Ultrasonic Testing, Destructive, MTR’s Available, Export Packaging, Material testing |
| ASTM A312 | Si | P | C | Mn | S | Cr | Mo | Ni | N | |
| 310s | min. | – | – | – | – | – | 24.0 | – | 19.0 | – |
| max. | 1.50 | 0.045 | 0.25 | 2.0 | 0.030 | 26.0 | 22.0 | – | ||
