ASTM A269 TP316L Stainless Steel Coil Tube For Heat Exchanger

ASTM A269 TP316L Stainless Steel Coil Tube For Heat Exchanger

  • ASTM A269 TP316L Stainless Steel Coil Tube For Heat Exchanger
  • ASTM A269 TP316L Stainless Steel Coil Tube For Heat Exchanger
ASTM A269 TP316L Stainless Steel Coil Tube For Heat Exchanger
Product Details:
Place of Origin: China
Brand Name: Yuhong Group
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: A269 TP316L
Payment & Shipping Terms:
Minimum Order Quantity: 100 kgs
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle
Delivery Time: 7 days
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
STANDARD: ASTM A269 NDT: HT/UT/ET
SURFACE: BRIGHT ANNEALED
High Light:

TP316L Stainless Steel Coil Tube

,

Heat Exchanger Stainless Steel Coil Tube

,

ASTM A269 Stainless Steel Pipe Coil

Austenitic Stainless Steel Coil Tube, ASTM A269 TP304 / TP304L / TP310S / TP316L





Stainless Steel Coil Tubes:
(1)Commodity name: Austenitic Stainless Steel Coil Tubes
(2)Process method: cold drawn/cold pilgered
(3)Material: TP304, TP304L,TP316, TP316L,dual grade 317L , 316Ti, TP321

(4)Standard: ASTM ( ASME) ,EN, DIN, JIS and etc.
(5)Specifications:a) O.D.:1/4" -3/4"
b) W.T.:0.028"- 0.065"
c) Length:customized, max:1000m/pc.
(6)Delivery conditions: annealed & pickled
(7)Applications: widely used in petrol, chemical, pharmacy, foodstuff, machinery, spaceflight,

war industry.

(8)boiler gas, hot water heating parts, hardware, shipping, power and other

industries.
(9)Packing: packed by weaving bags, then protected by seaworthy wooden case.



Material Grade:

American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501
GOST 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ



Stainless steel tube coils are ideal for use in potentially corrosive environments and for transferring liquids and gases for cooling, heating, and other purposes. From gas manifolds and plumbing to solar energy and medical equipment,YUHONG’s stainless steel tubing coils are effective in a wide range of applications.

ASTM A269 TP316L Stainless Steel Coil Tube For Heat Exchanger 0
