Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Model Number: | ASTM A213 TP316L |
| Minimum Order Quantity: | 100 KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 1500 Tons Per Month |
| Certification: | ISO, SGS, BV, ISO & SGS, ISO/CE/SGS | Steel Grade: | 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series |
|---|---|---|---|
| Type: | Seamless, Welded, Round Pipe/Tube | Standard: | ASTM, AISI, GB, DIN, JIS |
| Length: | 3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m | Thickness: | 0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm |
| Technique: | Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them | Product Name: | Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube |
| Outer Diameter: | 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm | Surface: | Annealing, 8K, Polishing Or Unpolishing, Morror/Satin |
| Finish: | Brush Polish, Cold Drawn, Pickled, Bright Annealed Or Un Annealed, Bright | Material: | Stainless Steel |
| Shape: | Seamless Tube | ||
| High Light: | Seamless Steel Tube Corrosion Resistance,ET HT Stainless Steel Seamless Pipe,Seamless Stainless Steel Tube Pipe |
||
ASTM A312 TP 316/316L pipe is a grade 316 stainless steel pipe with general properties that make it suitable for a wide range of application industries. The tube has excellent corrosion resistance, high strength at high temperature, excellent pitting resistance. Since 316 is inherently non-magnetic, so is the tube. 316L has a lower carbon content compared to 316 grades.
They use modern machinery and other latest technological tools to produce efficient quality pipes for domestic and global customers. In addition to this, they offer their customers some unparalleled pipe properties such as reliability, high-end finishing, durability and market price. The company uses high-quality raw materials to produce 316-grade pipes.
Test Certification: The industry provides customers with a variety of test certificates to ensure the quality and specification of the products they order. These tests are Manufacturer's TC according to EN 10204, Radiographic Test Report, Raw Material Test Certificate, Third Party Inspection Report.
Material Testing: ASTM A312 TP 316/316L tubing is inspected by professionals before final shipment to ensure its exacting quality. Hardness testing, mechanical testing, reliable material identification (PMI), intergranular corrosion testing (IGC), flaring testing, flattening testing, etc. are some of the tests performed on pipes.
Documents Provided: The company provides various documents with the tube. Fumigation certificates, quality assurance plans, welding procedure specifications, packing lists including net and gross weights, etc. are some of the documents the industry provides for pipes.
| GRADE | TENSILE STRESS (MPA) MIN |
YIELD STR 0.2% PROOF (MPA) MIN |
ELONG (% IN 50MM) MIN |
HARDNESS | |
|---|---|---|---|---|---|
| ROCKWELL B (HR B) MAX | BRINELL (HB) MAX | ||||
| SS 316L Tube | 485 | 170 | 40 | 95 | 217 |
| SS 316H Tube | 515 | 205 | 40 | 95 | 217 |
| MATERIAL | C | MN | SI | P | S | CR | MO | NI | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| SA213 TP 316L Tube | Min | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| SA213 TP 316H Tube | Min | 0.04 | 0.04 | 0 | - | - | 16.0 | 2.00 | 10.0 | - |
| max | 0.10 | 0.10 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | - |
| MATERIAL | UNS NO | OLD BRITISH | EN/ EURONORM | SWEDISH SS |
JAPANESE JIS |
||
|---|---|---|---|---|---|---|---|
| BS | EN | NO | NAME | ||||
| SA213 TP 316L Tube | S31603 | 316S11 | - | 1.4404 | X2CrNiMo17-12-2 | 2348 | SUS 316L |
| SA213 TP 316H Tube | S31609 | 316S51 | - | - | - | - | - |
Application:
