| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASTM A213/ASME SA213 |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply- Wooden Case/Plastic Bag / Plastic Cap |
| Delivery Time: | 10-75DAYS |
| Payment Terms: | L/C, T/T |
| Supply Ability: | ACCORDING TO CUSTOMER'S REQUEST |
| Material: | TP317L/1.4428/ UNS S31703 | Type: | Seamless Stainless Steel U Bending Tube |
|---|---|---|---|
| Application: | Heat Exchanger/Boiler | EDT: | HT,PT, ET, |
| High Light: | UNS S31703 U Bending Tube,Seamless Heat Exchanger U Tube,Stainless Steel U Bending Tube |
||
YUHONG GROUP has more than 20 years on the stainless steel tube/pipe manufacture, especially the boiler tube and heat exchanger tube. For the Austenitic grade 317L Stainless Steel Tube cover under the ASTM A213(ASME SA213) is designed to be use in the boiler, heat exchanger, super heater tube. ASTM A213(ASME SA213) also included some other Austenitic grade like 316L, 304L,321... If there is anything YUHONG can help, don’t hesitate to let us know 24/7.
| Element | AISI 317L |
| Density | 8.0 g/cm3 |
| Melting Range | 1454 °C (2650 °F) |
| Tensile Stress | Psi - 75000 , MPa - 515 |
| Yield Stress (0.2%Offset) | Psi - 30000 , MPa - 205 |
| Elongation | 35 % |
| Hardness (Brinell) | - |
| SS 317L | Maximum |
| Ni | 11 - 15 |
| C | 0.035 Maximum |
| Mn | 2 Maximum |
| P | 0.040 Maximum |
| S | 0.03 Maximum |
| Si | 1 Maximum |
| Cr | 18 - 20 |
| Mo | 3 - 4 |
| N | - |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317L | 1.4438 | S31703 |
