ASTM A268 TP409 / UNS S40900 / 1.4512 / SUS 409 Stainless Steel Seamless Tube

ASTM A268 TP409 / UNS S40900 / 1.4512 / SUS 409 Stainless Steel Seamless Tube

ASTM A268 TP409 / UNS S40900 / 1.4512 / SUS 409 Stainless Steel Seamless Tube
video
ASTM A268 TP409 / UNS S40900 / 1.4512 / SUS 409 Stainless Steel Seamless Tube
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, ISO 9001-2008, GL, DNV, BV, NK, PED, AD 2000, GOST9941-81
Model Number: ASTM A268 / ASME SA268 TP09 Stainless Steel Seamless Tube
Payment & Shipping Terms:
Minimum Order Quantity: 500KGS
Packaging Details: Plywood Case /Iron Case/ Bundle with plastic Cap/requirements
Delivery Time: 7 DAYS
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
Product Name: Stainless Steel Seamless Tube Standard: ASTM A268, ASME SA268
Material: TP409/TP410/TP405/TP420/TP430/TP430Ti/TP403/TP444/TP439/TP446,etc Type: Seamless, Welded
Surface: Polished, Bright Annealed, Picked And Annealed End: Beveled End, Plain End
Technique: Cold Drawn, Cold Rolled, Extrusion, Hot Rolled Tube Application: Heat Exchanger, Heater, Condenser, Machining, Bearing Machining, API Service
Package: Plywood Case /Iron Case/ Bundle With Plastic Cap/requirements Highlight: ASTM A268 TP430Ti Stainless Steel Seamless Tube
High Light:

TP409 Stainless Steel Seamless Tube

,

1.4512 Stainless Steel Tube

,

Polished Seamless Cold Drawn Steel Tube

ASTM A268 TP409 / UNS S40900 / 1.4512 / SUS 409 Stainless Steel Seamless Tube





Grade 409 is a titanium-stabilised ferritic stainless steel. Although regarded as a general-purpose chromium stainless steel the almost exclusive application for Grade 409 is automotive exhaust systems. Its applications are those where appearance is a secondary consideration to mechanical properties and corrosion resistance, particularly at high temperatures, and where some weldability is required.





ASTM A268 TP409 Stainless Steel Seamless Tube Specification

Outside Diameter 6-203mm
Wall Thickness 0.5-25mm
Length Up to 25m
Standard ASTM A268, ASME SA268
Grade TP410/TP405/TP420/TP430/TP430Ti/TP403/TP409/TP444/TP439/TP446,etc.
Delivery Condition Pickled, Polished, Bright Annealed
Technique Seamless/Welded
Application Heat Exchanger, Heater, Condenser, Machining, Bearing Machining, API Service…
Marking Standard, Grade, Size, Heat Number, Lot Number ...
Package Bundle with plastic Cap, Plywood case, or as per customer's requirement.
Quality Requirement Mill Test Certificate (EN 10204/3.1); 3.2, Third Part Inspection is acceptable.





ASTM A268 TP409 Stainless Steel Tube Equivalent Grades

Grade UNS No

Euronorm

Swedish  Japanese
No Name SS JIS
409 S40900 1.4512 X6CrTi12 / X2CrTi12 - SUS409





ASTM A268 TP409 Stainless Steel Tube Chemical compositions

Grade C Si Mn P S Cr Ni Ti
TP409, UNS S40900 0.08 max 1.00 max 1.00 max 0.045 max 0.030 max 10.5~11.7 0.5 max 6*C min, 0.75 max





ASTM A268 TP409 Stainless Steel Tube Mechanical properities

Tensile strength Yield strength Elongation
380 170 20





Material Grades







American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...



Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501



Russia Standard

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ





Applications

1. Off-Shore Oil Drilling Companies

2. Power Generation

3. Petrochemicals

4. Gas Processing

5. Specialty Chemicals

6. Pharmaceutical Equipment

7. Sea Water Equipment

8. Heat Exchangers

9. Condensers

10. Pulp & Paper Industry





ASTM A268 TP409 / UNS S40900 / 1.4512 / SUS 409 Stainless Steel Seamless Tube 0
