| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Model Number: | ASTM A269 TP304L |
| Minimum Order Quantity: | 100 KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 20-80 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1500 Tons Per Month |
| Certification: | ISO, SGS, BV, ISO & SGS, ISO/CE/SGS | Steel Grade: | 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series |
|---|---|---|---|
| Type: | Seamless, Welded, Round Pipe/Tube | Standard: | ASTM, AISI, GB, DIN, JIS |
| Length: | 3000mm-6000mm, 6 Meters Or Customized, 18000max., 11.8m Or As Required., 8m | Thickness: | 0.4-30mm, 1.0mm, 0.6mm-2500mm, 1mm-60mm, 0.6-25 Mm |
| Technique: | Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling Or Both Of Them | Product Name: | Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube, Factory Direct Sales Stainless Steel Pipe For Electric Heating Element, Seamless Stainless Steel Pipe/Tube |
| Outer Diameter: | 6-630mm, Customized, 6-762mm, 6-860mm;, 6mm-630mm | Surface: | Pickling |
| Finish: | Polished,Ba,pickled,Hairline Satin | Color: | Customerized |
| Condition: | Soft / Hard | Corrosion Resistance: | High |
| Hs Code: | 73044190 | Nde: | HT/ECT |
| Package: | Standard Export Package | Packing: | Plywood\wooden Pallets |
| Schedule: | SCH5 SCH10 SCH40S SCH80S SCH160S | Section Shape: | Round |
| Specification: | ASTM A269, ASME SA269 | Steel Grade: | 300 Series,304L,316L Etc |
| Surface Finish: | Polished | Tolerance: | ASTM A312 A269 A213 |
| High Light: | TP304L Seamless Heat Exchanger Tubes,ASTM A269 Heat Exchanger Tubes,Polish Stainless Steel Seamless Tube |
||
Yuhong Special Steel has been engaged in austenitic stainless steel, nickel alloy steel (Hastelloy, Monel, Inconel, Inconel) seamless welded pipes and pipes for more than 25 years, with an annual sales of more than 80,000 tons of steel pipes and pipes. pipeline. Our customers are located in more than 45 countries including USA, Canada, UK, Germany, Italy, Chile, Colombia, Saudi Arabia, South Korea, Singapore, Australia, Poland and France.
ASTM A269 TP304L grade covers low carbon 304L stainless steel pipe of nominal wall thickness. The ASTM A269 TP304L pipe is designed with an austenitic structure and is resistant to general corrosion due to its high embedded nickel and chromium content. General purpose grade ASTM A269 TP304L stainless steel pipe works well in both low and high temperature applications. The robust tube exhibits enhanced strength and resists attack from a range of reducing agents in stress-induced settings.
The ASTM A269 TP304L standard grade covers modules in both seamless and welded configurations. ASME SA269 Grade 304L Seamless Pipe is designed by passing hot billets through extruded metal to shape them to the correct size. This gives the tube superior strength and excellent load-carrying capacity compared to its welded counterparts. To improve the quality of the tubes, they are processed through a cold rolling procedure. SA269 Tp304L cold drawn seamless tube runs on molds at room temperature, giving the tube excellent strength and tolerance in difficult applications. The cold drawing process also helps to improve the surface area and overall properties of the tube. Contrary to seamless grades, the weld seam of A269 Type 304L welded pipe reduces its pressure bearing capacity. However, these tubes are less expensive than seamless tubes and are available in a variety of sizes. ASME SA269 316L welded pipe is inspected before modules are deemed suitable for high pressure and high temperature applications. These pipes are durable and require good maintenance. To learn more about this grade tube or to get a quote, please contact our salesperson for more information.
Standard Specification:
| Specification | ASTM A269 TP304L/ ASME SA269 TP304L Tube |
| Shapes | Hydraulic, Rectangular, Round, Honed Tubes, Square, Straight, U Shape, Coiled, Pan Cake Coils |
| Standard | ASTM, GB, DIN, JIS, AISI, EN, SUS |
| Surface Finish | 400G, BA, 2B, No.8, No.1, No.4, No.3, 500G, 8K, 2D, 1D, 180G, 320G, HL, 400G Satin/ Hairline, Mirror Polished, 600G or 800G Mirror finish Tubing or Custom Finish as per customer's specification |
| Manufacturing Type | CDS / Fabricated / Seamless / CDW / ERW / DOM / CEW / Welded / 100% X Ray Welded |
| Thickness Range | SCH XXS, SCH 10, SCH XXH, SCH 5, SCH 40, SCH XS, SCH 80S, SCH 160, SCH 80 |
| Technique | Cold drawn, Cold rolled, Extrusion, Hot rolled Tube |
| Delivery Condition | Polished, Cold Drawn, Annealed and Pickled (AP), MF, Bright Annealed (BA) |
| End | Beveled End, Treaded, Plain End |
| Processing Service | Cutting, Decoiling, Bending, Welding, Punching, Moulding |
| Grade | Manganese | Carbon | Phosphorus | Silicon | Chromium | Sulfur | Nickel | Nitrogen | |
| 304L | minimum. | 18.0 | 8.0 | ||||||
| maimum. | 2.0 | 00.030 | 00.045 | 00.75 | 200.0 | 00.030 | 12.0 | 00.10 | |
| Grade | Elongation | Yield Strength | Tensile Strength | Hardness | |
| Brinell (HB) maximum | Rockwell B (HR B) maximum | ||||
| ASTM A269 304L Tube | 40 | 170 | 485 | 201 | 92 |
| Grade | UNS No | Old British | Japanese JIS | Euronorm | Swedish SS | ||
| En | BS | Name | No | ||||
| ASTM A269 304L | S30403 | – | 304LS11 | SUS 304L | X2CrNi19-11 | 1.4306 | 2352 |
| Grade | UNS No | Old British | Japanese JIS | Euronorm | Swedish SS | ||
| En | BS | Name | No | ||||
| ASTM A269 304L | S30403 | – | 304LS11 | SUS 304L | X2CrNi19-11 | 1.4306 | 2352 |
Application:
