ASME SA182 F317L Forged Stainless Steel Ring Spacer Flange Paddle Spacers

ASTM A182 / ASME SA182 F317L / 1.4449 Stainless Steel Ring Spacer Flanges

A ring spacer flange, also known as a spectacle blind, is a type of flange fitting that is used to separate or isolate sections of a pipeline. It consists of a pair of metal discs that are joined together by a small, straight piece of metal. When installed in a pipeline between two flanges, a ring spacer flange allows the easy maintenance, inspection or modification of a line. They are essential components in many industrial applications, providing reliable spacing and alignment to ensure the efficient and safe operation of piping systems and equipment.

Types:

1. Ring Spacers: Circular spacers that fit between flanges to maintain a specific gap.

2. Paddle Spacers: Shaped like a paddle, these spacers are used in applications where a more substantial or specific shape is required to maintain spacing.

Benefits:

1. Corrosion Resistance: Stainless steel construction ensures long-lasting performance even in harsh environments.

2. Durability: High strength and resistance to wear and tear make these spacers reliable for long-term use.

3. Precision: Ensures precise spacing and alignment, which is crucial for the proper functioning of piping systems and equipment.

4. Versatility: Available in various sizes and configurations to suit different applications and requirements.

5. Ease of Installation: Designed for easy installation and removal, facilitating maintenance and repairs.

Equivalent Grade of ASME SA182 F317L Stainless Steel Flange

Chemical Composition of ASME SA182 F317L Stainless Steel Flange

Mechanical Strength of ASME SA182 F317L Stainless Steel Flange

ASME SA182 F317L Stainless Steel Flange

Flanges Grades

Stainless Steel Flange: F304, F304L, F304H, F316, F316L, F316Ti, F310, F310S, F321, F321H, F317, F317L, F347, F347H, F904L etc

Duplex Steel Flange: UNS S31803, 2205, S31254 (254SMO)

Super Duplex Steel Flange: UNS S32750, UNS S32760, UNS S32304, S31500

Carbon Steel Flange: ASTM A105, A105N etc.

Alloy Steel Flange: F1, F11, F22, F5, F9, F91 etc.

Nickel Alloy Flange as below

Monel 400 & K500,

Inconel 600, 601, 617, 625, 690, 718, X-750.

Incolloy 800, 800H, 800HT, 825, 925.

Hastelloy C22, C4, C276, S, C2000, G-30, G-35, X, N, B, B-2, B-3.


Application

• Piping Systems: Used in pipelines to maintain the correct distance between flanges, ensuring proper alignment and preventing stress on the pipes.

• Pressure Vessels: Employed in pressure vessels to ensure consistent spacing and alignment, which is crucial for maintaining structural integrity.

• Heat Exchangers: Utilized in heat exchangers to maintain the necessary gap between components, facilitating efficient heat transfer.

• Industrial Equipment: Found in various industrial machinery where precise spacing and alignment are critical for optimal performance.
