ASTM A270 TP316L Stainless Steel Sanitary Seamless Tube Bright Surface

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A270 TP316L

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	Depends on quantity
Payment Terms:	T/T, L/C AT SIGHT
Supply Ability:	1500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Stainless Steel Sanitary Tube	Shape:	Round, Square, Rectangle
Standard:	ASTM A270 / ASME SA270	Material:	TP316L
Surface:	Annealing / Pickling / Polishing / Bright	NDT:	ET, HT, PT
Highlight:	Bright Surface Sanitary Pipe , TP316L Stainless Steel Sanitary Pipe , ASTM A270 Sanitary Seamless Pipe

ASTM A270 TP316L Stainless Steel Sanitary Seamless Tube Bright Surface

Description

ASTM A270 is a standard specification of grades for sanitary applications. They can be cold worked, austenitic, or ferritic. A270 TP316L sanitary stainless tube works well in elevated pressure applications and showcases enhanced strength allowing it to be very robust in harsh environments. The tube are also tolerant to pitting by acids and crevice corrosion in the system.

The ASTM A270 Tp316l Seamless Tube is produced as hot steel billets are passed through extruded metal to put them in their correct position. This gives the tubes without any welds excellent strength and load-bearing capacity than the welded tubes.

ASTM A270 TP316L Chemical Composition

Grade	C	Si	Mn	Cr	Ni	Mo	S	P
TP316L	0.035	1.0	2	16 – 18	10 – 15	2 – 3	0.03	0.045

ASTM A270 TP316L Mechanical Properties

Grade	Temperure º F(º C)	Heat Treatment	Yield Strength.	Tensile Strength	Elongation
316L	1900(1040)	Solution	25(170)	70(485)	35

ASTM A270 TP316L Equivalent Grades

Standard	WERKSTOFF NR.	Unified Numbering System	GOST	British Standards	Japanese Industrial Standards	AFNOR	European Standards
TP316L	1.4404 / 1.4435	UNS S31603	03Ch17N14M3 / 03Ch17N14M2	316LS11 / 316LS13	SUS 316L	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3

ASTM A270 TP316L Physical Properties

Grade	Specific Heat 0-100°C (J/kg.K)	Density (kg/m3)	Elastic Modulus (GPa)	Thermal Conductivity (W/m.K)		Mean Coefficient of Thermal Expansion (μm/m/°C)			Electrical Resistivity (nΩ.m)
				at 100°C	at 500°C	0-100°C	0-315°C	0-538°C
TP316L	500	8000	193	16.2	21.5	17.2	17.8	18.4	720

Testing

Each tube shall be subjected to mechanical tests like reverse flattening test, hydrostatic test or nondestructive electric test, in practice eddy current testing is most used testing.

Application:
