| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | F321H |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PLYWOOD CASE,PALLET |
| Delivery Time: | Depends on quantity |
| Payment Terms: | T/T, L/C at sight |
| Supply Ability: | 10000Ton/Month |
| TYPE: | WNRF,BLRF | SIZE: | 1/2" TO 48" |
|---|---|---|---|
| WT: | Sch10s To XXS | STANDARD: | ASTM A182 |
Stainless steel 321H flanges have oxidation resistance to 16,000°F.
Developed to provide an 18-8 type alloy with improved resistance to intergranular corrosion. SS 321H flanges do not exhibit weld rot (intergranular corrosion) in mildly corrosive environments. SS 321H blind flanges are a titanium-stabilized chromium-nickel austenitic stainless steel with good strength and excellent corrosion resistance, supplied in the annealed condition. SS 321H plate flanges can be easily formed and drawn.
However, higher pressure requirements and more springback are encountered than with carbon and ferritic stainless steels. Stress Relief - Heat this stainless steel 321H socket eld flange up to 700°C for 1 to 2 hours with air cooling. s$ 321H threaded flange contains 18% chromium, 8% nickel and a significant addition of titanium.
Characteristic of ASTM A182 F321H
High temperature resistance: It has good high temperature resistance and can maintain good strength and corrosion resistance under high temperature environment.
Corrosion resistance: It has good corrosion resistance, especially for chloride and sulfuric acid and other corrosive media with good resistance.
High strength: It has high tensile strength and yield strength, making it suitable for high strength requirements of engineering applications.
Weldability: It has good weldability, can be connected by various common welding methods.
Chemical Composition of A182 F321H
Stainless Steel 321 Flanges |
|
|---|---|
| Ni | 9 – 12 |
| Cr | 17 – 19 |
| C | 0.08 maximum |
| N | 0.10 maximum |
| Fe | Balance |
| Mn | 2 maximum |
| Si | 0.75 maximum |
| S | 0.03 maximum |
| P | 0.045 maximum |
| Ti | 5xC min 0.60% maximum |
Mechanical Properties of A182 F321H
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) maximum | Brinell (HB) maximum | ||||
| Stainless Steel 321 Flanges | 515 | 205 | 40 | 95 | 217 |
| Stainless Steel 321H Flanges | 515 | 205 | 40 | 95 | 217 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| Stainless Steel 321 Flanges | 8027 | 193 | 16.6 | 17.2 | 18.6 | 16.1 | 22.2 | 500 | 720 |
Application
Oil and Gas Pipeline
Chemical Industry
Plumbing
Heating
Heat exchanger
Condenser
