ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger

ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger

  • ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger
  • ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger
  • ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger
  • ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger
ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number: ASME SA179
Payment & Shipping Terms:
Minimum Order Quantity: 100KG
Price: Negotiable
Packaging Details: Ply Wooden Case with Plastic Cap
Delivery Time: 5-60 Days
Payment Terms: L/C, T/T
Supply Ability: ACCORDING TO CUSTOMER'S REQUEST
Contact Now
All Products
Stainless Steel Seamless Pipe (290)
Stainless Steel Seamless Tube (277)
Duplex Stainless Steel Pipe (127)
Duplex Stainless Steel Tube (29)
Needle Tube (107)
Fin Tube (631)
Heat Exchanger (17)
Heat Exchanger Tube (424)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (116)
Heat Exchanger Baffle (36)
Air Cooler (8)
Pressure Vessel (4)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (114)
Nickel Alloy Pipe (261)
Nickel Alloy Tube (79)
Copper Alloy Tube (227)
Alloy Steel Tube (184)
Titanium Tube (10)
Bright Annealed Tube (153)
Boiler Tube (145)
Steel Fitting (804)
Steel Flange (590)
Others (391)
Cladding Parts (7)
Detailed Product Description
Surface: Black Printed Or Oil Surface Type: Seamless Carbon Steel Tube
Bending Radius: From 1.5 OD-1250MM Temperature: High Temperature
Material Grade: Carbon Steel Usage: Heat Exchanger/Boiler/Petroleum
Edt: HT,PT, ET, Application: Heat Exchanger, Boiler, Evaporator
Highlight:

Low Carbon Steel U Bend Tube

,

Carbon Steel Tube SA179-2021

,

Cold Drawn Heat Exchanger Tube

ASTM A179/ASME SA179-2021 Low Carbon Steel U Bending Tube Cold Drawn For Heat Exchanger







This specification covers minimum wall thickness cold drawn low carbon seamless steel tubes for tubular heat exchangers, condensers and similar heat transfer equipment.



As ASTM A179 U-tubes they are made of seamless cold drawn low carbon steel tubes. Made by seamless process and cold drawn. With good high temperature resistance, they are suitable for steel tubes for tubular heat exchangers, condensers and similar heat transfer equipment. Used in heat exchangers and boilers. These pipes are suitable for oil and gas plants, chemical and petrochemical plants, refineries, power plants and renewable energy plants.



Thermal analysis and product analysis should be carried out to ensure that the steel meets the chemical composition requirements such as carbon, manganese, phosphorus and sulfur. The steel should also be hardness tested, flattened, flared, flanging and hydrostatic pressure tested.











ASTM A179 Seamless Carbon Steel Tube Chemical Composition





Chemical Composition

C

Mn

P≤

S≤

Si≤

0.06-0.18

0.27-0.63

0.035

0.035

0.25











ASTM A179 Seamless Carbon Steel​ Tube Mechanical Property





Steel Grade

Yield Strength (Mpa)

Tensile Strength (Mpa)

Elongation (%)

ASTM A179

≥180

≥325

≥35











ASTM A179 Seamless Carbon Steel Tube Application





Seamless Cold Drawn Low Carbon Steel Heat Exchanger and Condenser Tubes

Applications:

For tubular heat exchangers,condensers,and similar heat transfer services.

Size (mm):

O.D.: 6.0~114.0; W.T.: 1~15; L: max 12000













Application







Power plant condenser: cooling water circulates inside the tube, steam condenses outside the tube



Low-pressure feedwater heater: recover waste heat and improve thermal efficiency (medium: clean water/low-pressure steam).



Chiller evaporator: refrigerant evaporates outside the tube, cold water circulates inside the U-tube.



Distillation tower reboiler: light hydrocarbons (such as propane, butane) vaporize in the bend section (temperature ≤200°C).



Solvent recovery heat exchanger: heat recovery system for non-corrosive organic solvents.



Economizer pipeline: preheat boiler inlet water (flue gas side temperature ≤400°C).



Low-pressure steam recovery pipe: condensation and reuse of waste heat steam.









ASTM A179 / ASME SA179 Low Carbon Steel U Bend Tube Cold Drawn For Heat Exchanger 0
