Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015, IEI |
| Model Number: | UNS S31803 |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Ply-wooden Case |
| Delivery Time: | Depends on quantity |
| Payment Terms: | T/T, L/C at sight |
| Supply Ability: | 10000 TONS PER MONTH |
| Inspection: | RT, UT, PT | TYPE: | SEAMLESS |
|---|---|---|---|
| Size: | 6'' | WT: | 10S |
Super Duplex Steel Pipe Fittings Elbow 90 Deg ASTM A815 UNS S31803 Branch Oil gas
Overwiew
ASTM A815 is the standard specification for wrought ferritic, ferritic/austenitic, and martensitic stainless steel pipe fittings.
UNS S31803 has a higher chromium content which gives it equal corrosion resistance. It exhibits very high resistance to stress corrosion cracking even in chloride and sulfide environments. However, it causes embrittlement at temperatures above 300°C.
In addition, UNS S31803 Equal Tee has good strength and elongation. At low temperatures, its notch ductility is superior to ferritic and martensitic grades. Its operating temperature is at least -50°C. Therefore, this stainless steel fitting is ideal for cryogenic applications.
Mechanical Properties of ASTM A815 UNS S31803 Elbow
| Tensile Strength, ksi |
.2% Yield Strength, ksi |
% Elongation in 50mm |
Hardness Max. |
|---|---|---|---|
| 109 | 80 | 25 | 28 HRC |
Equivalent Grades of ASTM A815 UNS S31803 Elbow
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| ASTM A815 WPS 31803 Duplex Fittings | 1.4462 / 1.4462 | S31803 / S32205 |
Chemical Composition of ASTM A815 UNS S31803 Elbow
| Cr |
Ni |
Mo |
C |
W |
Cu |
|---|---|---|---|---|---|
| 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 |
|
N |
Mn |
Si |
P |
S |
Fe |
| 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
Application
Oil and gas
Chemical
Power generation
Mining and mineral industries
Flue-gas desulfurization
