ASTM B622 UNS N10276 Seamelss Nickel Alloy Tube 2.4819 Hastelloy C276 Heat Exchanger Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS
Model Number:	ASTM B622 UNS N10276 Alloy C276 Seamless Nickel Alloy Tube

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7 DAYS
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (350)

Stainless Steel Seamless Tube (346)

Duplex Stainless Steel Pipe (137)

Duplex Stainless Steel Tube (39)

Needle Tube (172)

Fin Tube (750)

Heat Exchanger (41)

Heat Exchanger Tube (480)

Heat Exchanger Tube Bundle (55)

Heat Exchanger Tubesheet (130)

Heat Exchanger Baffle (39)

Air Cooler (14)

Pressure Vessel (4)

Stainless Steel Welded Pipe (62)

Stainless Steel Welded Tube (135)

Nickel Alloy Pipe (275)

Nickel Alloy Tube (110)

Copper Alloy Tube (258)

Alloy Steel Tube (224)

Titanium Tube (22)

Bright Annealed Tube (166)

Boiler Tube (163)

Steel Fitting (881)

Steel Flange (683)

Others (412)

Cladding Parts (9)

Detailed Product Description

Product Name:	Nickel Alloy Tube	Standard:	ASTM B622, ASME SB622
Material:	UNS N10276 / 2.4819 / Hastelloy C276	NDT:	Eddy Current Test , Hydrostatic Test , Ultrasonic Test
Length:	Single Random, Double Random & Cut Length	Type:	Seamless
Form:	Straight, U Bend	End:	Plain End, Beveled End, Treaded
Packing:	Plywood Case, Bundle With Plastic Cap
Highlight:	ASTM B622 nickel alloy pipe , Hastelloy C276 seamless tube , UNS N10276 nickel pipe

ASTM B622 Hastelloy C276 Seamless Tube UNS N10276 / EN 2.4819 Nickel Alloy Tube

ASTM B622 UNS N10276 Seamless Nickel Alloy Tube Heat Exchanger Tube (also identified by the unified numbering system as UNS N10276 and the European standard designation 2.4819, commercially known as Hastelloy C276) is a cold-finished or hot-finished seamless tubular product manufactured in compliance with the American Society for Testing and Materials (ASTM) standard B622, which governs seamless nickel and nickel-cobalt alloy pipe and tube for general corrosion-resistant and high-temperature service.

Equivalent Grades for ASTM B622 Hastelloy C276 Seamless Tube UNS N10276 / EN 2.4819 Nickel Alloy Tube

STANDARD	UNS	WNR.	AFNOR	EN	JIS	OR	GOST
Hastelloy C276	N10276	2.4819	-	NiMo16Cr15W	NW 0276	ЭП760	ХН65МВУ

Chemical Composition % of ASTM B622 UNS N10276 Seamelss Nickel Alloy Tube Hastelloy C276 Heat Exchanger Tube

Hastelloy C276	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy C276	Balance	0.010 max	15.00 – 17.00	1.00 max	0.08 max	4.00 – 7.00	0.04 max	0.03 max	2.5 max	14.50 – 16.50

Mechanical Properties of ASTM B622 UNS N10276 Seamelss Nickel Alloy Tube Hastelloy C276 Heat Exchanger Tube

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.89 g/cm3	1370 °C (2500 °F)	Psi – 52,000 , MPa – 355	Psi – 1,15,000 , MPa – 790	40 %

Why Hastelloy C-276 (UNS N10276) for Heat Exchangers?
Heat exchangers are the most demanding application for tubing. This alloy is chosen specifically because it offers:

Unmatched Corrosion Resistance: Excellent resistance to pitting, crevice corrosion, and stress corrosion cracking (SCC), especially in wet chloride, sulfuric acid, hydrochloric acid, and phosphoric acid environments.
Oxidizing & Reducing Media Resistance: Unlike 300-series stainless steels, C-276 resists both oxidizing and reducing chemicals. It stands up to mixed acids (e.g., HNO₃ + HCl) where most metals fail.
Fouling Resistance: The smooth, high-nickel surface resists scale and polymer buildup, maintaining heat transfer efficiency over long operational cycles.
High-Temperature Stability: Can operate continuously in heat exchangers up to ~400°C (750°F) in corrosive environments, and up to ~1000°C (1832°F) in oxidizing conditions for short durations.
Fabrication: Excellent ductility allows it to be easily rolled and expanded into tubesheets, and bent into U-tube configurations without cracking.

Applications
These tubes are often used in industries such as chemical processing, pulp and paper, and waste treatment, where resistance to corrosion and high temperatures is critical.

1. Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings.
2. Flue gas desulfurization systems.
3. Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping.
4. Sour gas wells.
5. Pulp and paper production.
6. Waste treatment.
7. Pharmaceutical and food processing equipment.

ASTM B622 UNS N10276 Seamelss Nickel Alloy Tube 2.4819 Hastelloy C276 Heat Exchanger Tube
