EN 10216-5 And B983 Inconel NO7718 Seamless Tube For Petrochemical Industries

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number:	B983 NO7718

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	10-90 Days
Payment Terms:	L/C, T/T
Supply Ability:	According To Client's Request

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Standard:	B983	Grades:	NO7718
Prodcut:	Steel Pipe Tube	Type:	Nickel Pipe, Seamless
Size:	8"~32	Length:	Customized
Highlight:	B983 Inconel NO7718 Seamless Tube , Petrochemical Industries Inconel NO7718 Seamless Tube , EN 10216-5 inconel no7718 seamless tube

EN 10216-5,B983 NO7718 Nikel Alloy Steel Seamless Tube

EN 10216-5 and B983 are industry standards for seamless tubes made from nickel alloy steel. NO7718 is the specific grade of nickel alloy steel used in the manufacture of the seamless tube. This type of steel is highly resistant to corrosion and oxidation, making it ideal for use in high-temperature and high-pressure applications such as in the chemical and petrochemical industries. The seamless tube made from this steel is designed to withstand extreme conditions and to provide reliable performance over a long service life.

INCONEL 718 COLD FINISHED PIPES EQUIVALENT GRADES

STANDARD	WERKSTOFF NR.	UNS
Inconel 718	2.4668	N07718

CHEMICAL COMPOSITION OF ASTM B983 UNS N07718 SEAMLESS PIPE

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Inconel 718	0.08 max	0.35 max	0.35 max	0.015 max	0.30 max	-	50.00 - 55.00	17.00 - 21.00

MECHANICAL PROPERTIES OF ASME SB 163 INCONEL 2.4668 ROUND PIPES

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Inconel 718	8.2 g/cm3	1350 °C (2460 °F)	Psi – 1,35,000 , MPa – 930	Psi – 75,000 , MPa – 482	45 %
