Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| Model Number: | ASTM A268 |
| Minimum Order Quantity: | 100 PC |
|---|---|
| Price: | 1-120000 USD |
| Packaging Details: | Ply-wooden Case / Bundle With Plastic Cap |
| Delivery Time: | 5-65 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1500tons/month |
| Product: | Seamless Tube | Materialrd: | Ferritic And Martensitic Stainless Steel |
|---|---|---|---|
| Standard: | ASTM A268 | Grade: | TP410 |
| Application: | Foreneral Corrosion-resisting / High-temperature Service | Length: | Or As Required |
| Certificate: | ISO9001-2008, API 5L, API 5CT, Etc. | Packing Details: | Ply-wooden Case / Bundle With Plastic Cap |
| High Light: | Ferritic Steel Tubes,Martensitic Steel Tubes,Stainless Steel Seamless Tube TP410 |
||
ASTM A268 Seamless TP410 Ferritic Martensitic Steel Tubes
YUHONG Group offers ASTM A268 TP410 SMLS/WELDED ferritic martensitic stainless steel tubes and we sell these tubes in more than 70 countries up to now. This specification covers a number of grades of nominal-wall-thickness, stainless steel tubing for general corrosion-resisting and high-temperature service.
Grade TP410 ferritic martensitic stainless steel, with 11.5% chromium, which provide good corrosion resistance properties. What's more, the corrosion resistance of grade 410 steels can be further enhanced by a series of processes such as hardening, tempering and polishing. Quenching and tempering can harden grade 410 steels.However, it doesn't be suitable for highly corrosive environments containing strong acids or chlorides. In such cases, a more corrosion-resistant stainless steel grade, such as TP316 or TP304, may be preferred.
And TP410 this material offers good strength, hardness, and wear resistance, making it suitable for demanding environments.
Specifications
| Standard | ASTM A268 |
| Name of Material | Ferritic and Martensitic Stainless Steel Tubes----Seamless or Welded |
| Keywordas | Ferritic stainless steel; welded steel tube, etc. |
| Condition | Annealed |
| Quantity | Feet,metres,or number of lengths |
| Length | Specific or random |
Applications
These tubes are suitable for applications where resistance to corrosion, high temperatures, and mechanical stresses is required,involving mild corrosion, heat resistance and high strength.
Boilers and Condensers
Shell and Tube Heat Exchangers
Process Heaters
Refinery Equipment
Petrochemical Plants
Power Generation Facilities,etc.
Chemical Composition %
| Grade | Cr | C | Ni | Mn | Si | P | S |
| max. | max. | max. | max. | max. | max. | ||
| TP410 | 11.5-13.5 | 0.15 | 0.75 | 1 | 1 | 0.04 | 0.03 |
Mechanical Properties
| Grade | Tensile Strength Min | Yield Strength Min | Elongation Min | HardnessMax |
| TP410 | 485 MPa (70,300 psi) | 275 MPa (40,000 psi) | 20% | Rockwell B hardness of 95 |
Tolerances
| Outside Diameter, In.[Mm] | OD Tolerance, In.[Mm] | Wall Thickness, % | Thin Wall Tubes |
| Up To1⁄2, [12.7], Excl | ±0.005 [0.13] | ±15 | |
| 1⁄2 To 11⁄2 [12.7 To 38.1], Excl/Td> | ±0.005 [0.13] | ±10 | Less Than 0.065 In. [1.6 Mm] Nominal |
| 11⁄2 To 31⁄2 [38.1 To 88.9], Excl | ±0.010 [0.25] | ±10 | Less Than 0.095 In. [2.4 Mm] Nominal |
| 31⁄2 To 51⁄2 [88.9 To 139.7], Excl | ±0.015 [0.38] | ±10 | Less Than 0.150 In. [3.8 Mm] Nominal |
| 51⁄2 To 8 [139.7 To 203.2], Incl | ±0.030 [0.76] | ±10 | Less Than 0.150 In. [3.8 Mm] Nominal |
Test Required
Chemical Analysis/ Mechanical Properties/ Hardness Test/ Flattening Test/ Tension Test/ FlaringTest
Intergranular Corrosion Test/ Hydrostatic or Nondestructive Electric Test/ Ultrasonic Test,etc
Contact Person: Isabel Yao
Tel: +8618268758675
Fax: 0086-574-88017980
