Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Minimum Order Quantity: | 500KGS |
|---|---|
| Price: | NEGOTIABLE |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | 10-90 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | According To Client's Request |
| Material: | It Covers Single-wall, Double-wall, Copper-brazed Steel Tubing, Zinc-coated Steel Tubing Suitable Fo | Unit Pipe Length: | 3 Meter |
|---|---|---|---|
| Shape: | Precision Double Copper Welded Steel Tubes Dimension, Mm Tolerance, Mm Mechanical Properties OD WT O | Finish: | Polished |
| Type | Double Wall (TDW) | Single Wall (TSW) |
| Welding Technique | Copper brazing | High frequency ERW |
| Resizing Method | Cold drawn | Cold drawn |
| Seam | 720 Degree seamless | Straight line seamed |
| Dimensional Accuracy | High | High |
| Strength | Mostly made hard | Can be soft or hard |
| Inside Clearliness | Good | Poor |
| Vibration Resistance | Strong | Poor |
| Safety against Pressure | High | Low |
| Application | Automobile brake lines, fuel lines, transmission cooler lines, power steering lines; certain hydraulic pipes, etc; | AC, refrigeration, heat exchanagers, automobile fuel lines; compressors, etc; |
| Original Surface | Copper | None (steel) |
| Surface Coating | Copper | Zinc |
| Zinc | GALFAN | |
| GALFAN | PVF | |
| PVF | Nylon | |
| Nylon | Epoxy | |
| Epoxy | Nickel | |
| Nickel |
The Bundy tube, also known as the Bundy pipe, is a type of metal tubing that is commonly used in various applications. Some of the key applications of Bundy tubes include:
1. Automotive Industry: Bundy tubes are extensively used in the automotive industry for manufacturing brake lines, fuel lines, and transmission cooling lines. These tubes are preferred due to their high strength, corrosion resistance, and ability to withstand high pressure and temperature.
2. Refrigeration and Air Conditioning: Bundy tubes are widely used in refrigeration and air conditioning systems for the transportation of refrigerants and coolants. The tubes' excellent heat transfer properties and resistance to corrosion make them ideal for these applications.
3. Hydraulic Systems: Bundy tubes find applications in hydraulic systems, such as in construction equipment, agricultural machinery, and industrial machinery. They are used for the transportation of hydraulic fluids and are known for their durability and resistance to high pressure.
4. Plumbing and Gas Distribution: Bundy tubes are also used in plumbing and gas distribution systems. They are used for transporting water, gas, or other fluids in residential, commercial, and industrial buildings. The tubes' resistance to corrosion and ability to withstand high pressure and temperature make them suitable for these applications.
5. Medical Equipment: Bundy tubes are utilized in medical equipment, such as oxygen delivery systems and anesthesia machines. These tubes are preferred due to their high purity, resistance to corrosion, and ability to withstand sterilization processes.
6. Industrial Applications: Bundy tubes are used in various industrial applications where the transportation of fluids or gases is required. These include power generation plants, chemical processing plants, and oil and gas refineries.
