B16.9 ASTM A403 WP316L Stainless Steel 45Deg LR Elbow Buttweld Pipe Fittings

ASME B16.9 is a standard that covers the overall dimensions, tolerances, ratings, testing, and markings for factory-made wrought buttwelding fittings in sizes NPS 1/2 through NPS 48 (DN 15 through DN 1200). The function of butt-welding pipe fittings is to join or connect pipes together in a permanent and leak-proof manner. These fittings are designed for use in pipelines where a smooth and uninterrupted flow of fluids is essential. They provide a strong and reliable connection by welding the ends of two pipes directly together.

Buttwelding fittings come in various types, such as elbows, tees, reducers, caps, and crosses. Each type serves a specific purpose:

1. Elbows: Elbows are used to change the direction of flow in a pipeline. They come in different angles, such as 45 degrees and 90 degrees, allowing for smooth directional changes.

2. Tees: Tees have three openings and are used to create branches in a pipeline, dividing the flow into multiple directions.

3. Reducers: Reducers are used to connect pipes of different sizes, allowing for a smooth transition in pipe diameter within a pipeline.

4. Caps: Caps are used to seal the end of a pipe. They provide protection and prevent leakage.

5. Crosses: Crosses have four openings and are used to create junctions in a pipeline, allowing flow in multiple directions.

These fittings are widely used in various industries, including oil and gas, chemical, petrochemical, power plants, and plumbing systems, to name a few. They are commonly made from materials such as stainless steel, carbon steel, or alloy steel, depending on the specific application requirements.

Other Material Grades:

Nickel Alloy
ASTM / ASME SB 336 UNS 2200 (NICKEL 200), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400), UNS 8020 (ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600), UNS 6601 (INCONEL 601), UNS 6625 (INCONEL 625), UNS 10276 (HASTELLOY C 276)
Stainless Steel
ASTM / ASME SA 403 GR WP "S" / "W" / " WX" 304 , 304L, 304H, 304N, 304LN, 309, 310H, 316, 316H, 317, 317L, 321, 321H, 347, 347 H.
Duplex Steel
ASTM / ASME SA 815 UNS NO.S 31803, S 32205, S 32550, S 32750, S 32760.
Carbon Steel
ASTM / ASME A 234 WPB, WPC
ASTM / ASME A 860 WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel
ASTM / ASME A 234 WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 23, WP 91

Applications

• Oil and gas industry
• Medical Gas Pipeline Systems
• Pharmaceutical processing industry
• Fluid piping
• Modern architecture
• Water waste projects
• Pipeline projects
• Onshore and offshore
• Power Generation
