Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | China |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | ASME SB111 UNS C71500, CuNi 70/30, 2.0882 |
| Minimum Order Quantity: | 500 KGS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-Wooden Case /Iron Case/ Bundle with Plastic Cap |
| Delivery Time: | 5 - 90 Work Days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | According To Customers' Request |
| Standard: | ASTM B111, ASME SB111, BS EN 1057 | Material Grade: | UNS C71500, CuNi 70/30, 2.0882, BFe30-1-1,CuNi30Mn1Fe |
|---|---|---|---|
| Type: | Seamless, Welded | Temper: | O61, HR50 |
| Outside Diameter: | 2mm~914mm | Wall Thickness: | 0.7-10mm |
| Length: | 6m,or As Required | Alloy Or Not: | Is Alloy |
| Shape: | Round | Applications: | Construction,Gas And Oil Plants,Air,Steam,Petroleum Gas Water |
| High Light: | 2.0882 Copper Nickel Alloy Seamless Tube,Seamless Tube ASME SB111,Copper Nickel Alloy Seamless Round Tube |
||
ASME SB111 UNS C71500 O61, CuNi 70/30, 2.0882 Copper Nickel Alloy Seamless Tube
ASME SB111 UNS C71500(CuNi 70/30, 2.0882, BFe30-1-1) Copper Nickel Alloy Tube has been added iron and manganese for good corrosion and biofouling resistance. The higher nickel content than copper-nickel 90/10 has enhanced mechanical properties and still maintains excellent corrosion resistance. CuNi 70/30 Copper Nickel Alloy Seamless Tubes are widely used in applications, like heat exchangers, oil and gas plant, chemical industry, petrochemical industry, ship building, marine systems.
Specification:
| Specification | ASTM B111, ASME SB111 |
| Standard | GB, DTD, ASME, AISI, ASTM, TOCT, JIS, NF, SAE, DIN, AMS, DS, EN |
| OD Size | 3.35 mm To 101.6 mm |
| Bwg & Swg | 10Swg, 12Swg, 14Swg, 16Swg, 18Swg, 20Swg, 22Swg, 25Swg. |
| Length | 6M Or Standard & Cut length , Single Random, Double Random Pipe |
| Finish | AP (Annealed & Pickled), BA (Bright & Annealed), 2B, Polished, etc |
| End | Plain End, Beveled End, Treaded ends |
| Form | Round, Straight, “U” Shape |
| Type | Seamless, Welded |
Chemical Composition:
| Grade | Cu | Ni | Fe | Mn | Pb | Zn |
| C70400 | Rem | 4.8-6.2 | 1.3-1.7 | 0.3-0.8 | 0.05 max | 1.0 max |
| C70600 | Rem | 9.0-11.0 | 1.0-1.8 | 1.0 max | 0.05 max | 1.0 max |
| C71500 | Rem | 29.0-33.0 | 0.4-1.0 | 1.0 max | 0.05 max | 1.0 max |
| C71640 | Rem | 29.0-32.0 | 1.7-2.3 | 1.5-2.5 | 0.05 max | 1.0 max |
Mechanical Properties:
| Grade | Temper |
Tensile Strength Mpa |
Yeild Strength Mpa |
Elongation % |
Expansion Requirement % |
| Min | Min | Min | Min | ||
| C70400 | 061 | 260 | 85 | - | 30 |
| H55 | 275 | 205 | - | 20 | |
| C70600 | 061 | 275 | 105 | - | 30 |
| H55 | 310 | 240 | - | 20 | |
| C71500 | 061 | 360 | 125 | - | 30 |
| HR50A | 495 | 345 | 12 | 20 | |
| HR50B | 495 | 345 | 15 | 20 | |
| C71640 | 061 | 435 | 170 | - | 30 |
| HR50 | 560 | 400 | - | 20 |
Applications:
Power Stations
Seawater Desalination
Petrochemical Plants
Shipbuilding
Electrical Appliances
Instrumentation
Medical Equipment
Desalination Plant
Sea Water Pipework
