Yuhong Holding Group Co.,LTD
 |
| Place of Origin: | CHINA |
| Brand Name: | YUHONG |
| Certification: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015 |
| Model Number: | ASTM A403 WP304 |
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Ply-wooden Case /Iron Case/ Bundle with plastic Cap |
| Delivery Time: | Depends on quantity |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 tons per month |
| Product Name: | Stainless Steel BW Elbow | Specification: | ASME SA403 WP316L |
|---|---|---|---|
| Type: | Buttweld | Schedule: | SCH 5- SCH XXS |
| WP Grade: | Seamless | Surface Treatment: | Sand Rolling / Sand Blasting |
| High Light: | Buttweld 90 Degree Elbow,Stainless Steel Elbow ASTM A403,Butt Weld Pipe Fitting B16.9 |
||
ASTM A403 WP316L-S Stainless Steel 90 DEG Elbow Buttweld Pipe Fitting B16.9
What is a stainless steel elbow?
A stainless steel elbow is a pipe fitting used in plumbing and piping systems to change the direction of the piping. It is typically made of stainless steel, a corrosion-resistant and durable material, making it suitable for various applications where protection against rust and corrosion is important. Stainless steel elbows come in different angles (45 degrees, 90 degrees, 180 degrees) to accommodate specific piping layouts and requirements. They are commonly used in industries such as chemical processing, food and beverage, pharmaceuticals, and more.
What is grade SS316L/UNS S31603?
Grade SS316L, also known as UNS S31603, is a low carbon version of stainless steel grade 316. It contains less carbon than 316 stainless steel, which helps to reduce the risk of sensitization (the formation of chromium carbide deposits, which can lead to intergranular corrosion).This makes SS316L suitable for applications where welding is required or where the material will be exposed to corrosive environments. The "L" in SS316L stands for "Low carbon," indicating the reduced carbon content compared to standard 316 stainless steel.
SS316L Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength | Elongation |
| 8.0 g/cm3 | 1040 °C (1900 °F) | ksi – 75, MPa – 515 | ksi – 30 , MPa – 205 | 35 % |
SS316L Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
| SS 316L | 0.030 max | 2.00 max | 1.00 max | 0.045 max | 0.030 max | 16.00 - 18.00 max | 2.00 – 3.00 max | 10.00 – 14.00 max |
SS316L Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN |
| SS316L | 1.4404 | S31603 | SUS 316L | 03Ch17N14M3 | X2CRNIMO17-12-2 |
WP316L Fittings Application:
Chemical Processing
Food and Beverage
Pharmaceuticals
Petrochemical
Water Treatment
Marine Applications
