SUS304 Stainless Steel Seamless Pipe for Chemical Processing in JIS G3459 Standard

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number:	JIS G3459 SUS304

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	10-90 Days
Payment Terms:	L/C, T/T
Supply Ability:	According To Client's Request

Contact Now

All Products

Stainless Steel Seamless Pipe (278)

Stainless Steel Seamless Tube (267)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (91)

Fin Tube (605)

Heat Exchanger (10)

Heat Exchanger Tube (421)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (75)

Copper Alloy Tube (211)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (787)

Steel Flange (576)

Others (384)

Detailed Product Description

Grade:	SUS304	Price Terms:	FOB,CIF,CFR,EXW
Material:	Stainless Steel	Outer Diameter:	1/8"-48"
Thickness:	XXS-S160	Standard:	JIS G3459
Highlight:	G3459 Stainless Steel Seamless Pipe , Chemical Processing Stainless Steel Seamless Pipe

JIS G3459 SUS304 Stainless Steel Pipe

The JIS G3459 standard specifies stainless steel pipes (hereinafter referred to as "pipes") for corrosion-resistant, low-temperature, and high-temperature pipes.

SUS304 is one of the steel types in the JIS G3459 standard.

Pipes should be manufactured using seamless processes, automatic arc welding processes, laser welding processes or resistance welding processes.

Heat treatment of JIS G3459 SUS304 Stainless Steel Pipe

Classification	Grade	Solution treatment ℃
Austenitic pipes	SUS 304TP	1010 min, rapid cooling

Chemical composition

Grades	Chemical composition
Grades	C	Si	Mn	P	S	Ni	Cr
SUS 304 TP	0.08 max.	1.00 max.	2.00max.	0.040 max.	0.030 max.	8.00~11.00	18.00~20.00

Mechanical properties

Grade	Mechanical properties
	Tensile strength	Yield Strength	Elongation %
	kgf/mm 2 {N/mm2}	kgf/mm 2 {N/mm2}	No. 11 test piece No. 12 test piece	No.5 test piece	No.4 test piece
			Longitudinal direction	Transverse direction	Longitudinal direction	Transverse direction
SUS 304 TP	53{520}min.	21{206} min	35 min	25 min	30 min	22 min

Dimensional tolerances

Division	Tolerances on outside diameter	Tolerances on wall thickness	Tolerances on eccentricity
ot-finished seamless pipe	Under 50mm 【0.5mm	Under 4mm 【0.5mm	At most 20 % of wall thickness
ot-finished seamless pipe	50mm or over 【1%	4mm or over 【12.5%	At most 20 % of wall thickness
Cold-finished seamless pipe, automatic arc welded pipe, electric resistance welded pipe, and laser welded pipe	Under 30mm 【0.3mm	Under 2mm 【0.2mm	—
	30mm or over 【1%	2mm or over 【10%	—
