ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection

ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection

  • ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection
  • ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection
  • ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection
  • ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection
ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection
Product Details:
Place of Origin: CHINA
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: ASTM A269 TP316L
Payment & Shipping Terms:
Minimum Order Quantity: 1000KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time: 10days->
Payment Terms: T/T, L/C
Supply Ability: 1500 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (277)
Stainless Steel Seamless Tube (269)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (86)
Fin Tube (596)
Heat Exchanger (10)
Heat Exchanger Tube (419)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (113)
Nickel Alloy Pipe (258)
Nickel Alloy Tube (75)
Copper Alloy Tube (210)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (784)
Steel Flange (574)
Others (384)
Detailed Product Description
Grade: TP316L Type: Seamless
Surface: Bright Annealed Test: Flaring Test, Hardness Test, Reverse Flattening Test, Hydrostatic Test, Nondestructive Electric Test
Packing: Wooden Pallet
Highlight:

A269 316L Stainless Steel Coiled Tubing

,

Bright Annealed Stainless Steel Coiled Tubing

,

A269 Stainless Steel Coiled Tubing

ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection



Coiled tubing is a long metal tube that is wrapped or coiled around a large spool and delivered to the well site during well reconstruction or repair.

YUHONG's stainless steel coils are suitable for potentially corrosive environments, as well as for liquid and gas transport for cooling, heating and other purposes. From gas manifolds and pipelines to solar energy and medical equipment, Yuhong's stainless steel coils are used in a wide range of applications with outstanding results.

ASTM A269 TP316L Stainless Steel Coiled Tube


(1)Commodity name: Austenitic Stainless Steel Coil Tubes
(2)Process method: cold drawn/cold pilgered
(3)Material: TP304, TP304L,TP316, TP316L,dual grade 317L , 316Ti, TP321

(4)Standard: ASTM ( ASME) ,EN, DIN, JIS and etc.
(5)Specifications:a) O.D.:1/4" -3/4"
                            b) W.T.:0.028"- 0.065"
                            c) Length:customized, max:500m/pc.
(6)Delivery conditions: annealed & pickled
(7)Applications: widely used in petrol, chemical, pharmacy, foodstuff, machinery, spaceflight,

war industry.

(8)boiler gas, hot water heating parts, hardware, shipping, power and other

industries.
(9)Packing: packed by weaving bags, then protected by seaworthy wooden case.

Dimensional Range for ASTM A269 TP316L Stainless Steel Coiled Tube (Bright Annealed)



arameter​​ ​​Range​​ ​​Tolerance​​
​​Outer Diameter (OD)​​ 1/8" (3.18 mm) to 3" (76.2 mm) ±0.005" (±0.13 mm) for small OD
​​Wall Thickness​​ 0.028" (0.71 mm) to 0.165" (4.19 mm) ±10% of nominal thickness
​​Coil Length​​ Up to 500 ft (152 m) per coil* Varies by manufacturer
​​Straightened Length​​ Custom-cut (e.g., 1 ft to 20 ft) ±1/8" (±3.18 mm)

ASTM A269 TP316L Stainless Steel Coiled Tube​ Chemical Composition



Elements 316L (wt%) S31603 316 (wt%) S31600
(C) Carbon, max 0.035 0.08
(Mn) Manganese, max 2 2
(P) Phosphorus, max 0.045 0.045
(S) Sulfur, max 0.03 0.03
(Si) Silicon, max 1 1
(Ni) Nickel 10.0 - 14.0 10.0 - 14.0
(Cr) Chromium 16.0 - 18.0 16.0 - 18.0
(Mo) Molybdenum 2.0 - 3.0 2.0 - 3.0
(Fe) Iron Bal. Bal.
(Cu) Copper N/A N/A
(N) Nitrogen N/A N/A

ASTM A269 TP316L Stainless Steel Coiled Tube Material Grade



American Standard

Austenitic Steel:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H,  TP317,TP317L, TP321, TP321H,TP347, TP347H,904L…

Duplex Steel :

S32101,S32205,S31803,S32304,S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

GOST

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ

ASTM A269 TP316L Stainless Steel Coiled Tube Bright Annealed for Chemical Injection 0
