ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG SPECIAL STEEL
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A268 TP430

Payment & Shipping Terms:

Minimum Order Quantity:	1000KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80 Days
Payment Terms:	L/C, T/T
Supply Ability:	800Tons/ month

Contact Now

All Products

Stainless Steel Seamless Pipe (278)

Stainless Steel Seamless Tube (267)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (91)

Fin Tube (605)

Heat Exchanger (10)

Heat Exchanger Tube (421)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (75)

Copper Alloy Tube (211)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (787)

Steel Flange (576)

Others (384)

Detailed Product Description

Standard:	ASME SA268	Grade:	TP430
Heat Treatment:	Pickled Surface	Application:	Oil And Gas Industry
Test:	Tension Test, Flaring Test, Hardness Test, Reverse Flattening Test, Hydrostatic Test, Nondestructive Electric Test, Intergranular Corrosion Test
Highlight:	Power Plant Stainless Steel Tube , Ferritic Stainless Steel Tube , A268 TP430 Stainless Steel Tube

ASME SA268 TP430 S43000 Ferritic Stainless Steel Seamless Tube for Oil and Gas Industry

We are one of the largest manufacturers of stainless steel, duplex and alloy steel pipes in China. After more than 20 years of development, we have accumulated a large number of customers all over the world, and Yuhong products have won the praise of our customers.

ASME SA268 is a standard specification for seamless and welded tubes and pipes of ferritic and martensitic stainless steels for general purposes, in grades TP410, TP405, TP420, TP430, TP430Ti, TP403, TP409, TP444, TP439, and TP446 etc..

ASME SA268 TP430 Stainless Steel Seamless Tube Chemical Composition

Grade:	TP410	TP430	TP439
UNS	S41000	S43000	S43035
C, Max	0.15	0.12	0.07
Mn,Max	1	1	1
P, Max	0.04	0.04	0.04
S, Max	0.03	0.03	0.03
Si, Max	1	1	1
Ni	…	…	0.50max
Cr	11.5-13.5	16.0-18.0	17.00-19.00
Mo	…	…	…
Al	…	…	0.15
Cu	…	…	…
N	…	…	0.04
Ti	…	…	0.20+4(C+N)Min, 1.10max

ASME SA268 TP430 Stainless Steel Seamless Tube Mechanical Properties

Grade	Tensile Strength, Min, Ksi [MPa]	Yield Strength, Min, Ksi [MPa]	ELONGATION. MIN, %
TP410	55 [380]	30 [205]	20
TP430	60 [415]	35 [240]	20
TP439	60 [415]	30 [205]	20

ASME SA268 TP430 Stainless Steel Seamless Tube Physical Properties

Density, g/cm3 (lb/in.3)	7.8 (0.28)
Melting point, °C (°F)	1425-1510 (2600-2750)
Specific heat capacity, J/kg · K (Btu/lb · °F)	460 (0.11) at 0-100 °C (32 to 212 °F)
Electrical resistivity, μΩ·m	0.60 at 20 ℃
430 stainless steel magnetic permeability	600-1100 (Approximate)
Elastic modulus (Modulus of elasticity), GPa (106 psi)	200 (29.0)
Thermal diffusivity, mm2/s	7.3
Thermal conductivity, W/m · K (Btu/ft · h · °F)	26.1 (15.1), at 100 ℃ (212 °F)
Thermal conductivity, W/m · K (Btu/ft · h · °F)	26.3 (15.2), at 500 ℃ (932 °F)
Coefficient of thermal expansion, μm/m · °C (μin./in. · °F)	10.4 (5.8), at 0-100 ℃ (32-212 °F)
	11.0 (6.1), at 0-315 ℃ (32-600 °F)
	11.4 (6.3), at 0-538 ℃ (32-1000 °F)
