ASTM B111 C68700 Aluminum Brass Tube Copper Alloy Tube EN 10204/3.1B

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, BV, DNV-GL , PED, TUV, LR, KR, NK, CCS.
Model Number:	ASTM B111 C68700 Aluminum Brass Tube Copper Alloy Tube

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	NEGOTIABLE
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	20-80
Payment Terms:	L/C, T/T

Contact Now

Standard::

ASME SB111

Material::

C68700

Testing:

ET, HT, Flattening Test; Expansion Test, Mercurous Nitrate Test; Ammonia Vapor Test; Chemical Analysis; Microscopical Examination; Tension Testing.

Surface:

Polished

Shape:

Round Pipe

Finish:

Cold Drawn

Length:

1-12m,Customers' Requirement

Application:

Air Condition Or Refrigerator,Water Tube,water Pipe,Oil Cooler Pipe,Water Heater

Product Name:

Copper Coil Tube,copper Alloy Square Pipe / Tube For Continous Casting Machine,High Hardness C17500 C17510 Copper Alloy Tube,China Manufacture Customized Brass Pipe Copper Tube Price Per Kg,Refrigerator Copper Pipe

Material:

Copper,aluminum

Highlight:

Standard Grade	ASTM B 111 C68700	EN 12451 CuZn20Al2As	DIN 17660/1785 CuZn20Al2	BS 2871 CZ 110	JIS H3300 C68700
Cu	76-79	76-79	76-79	76-78	76-79
Al	1.8-2.5	1.8-2.3	1.8-2.3	1.8-2.3	1.8-2.5
Fe	0.06 max	0.07 max	0.07 max	0.06 max	0.06 max
Pb	0.07 max	0.05 max	0.07 max	0.07 max	0.07 max
Zn	Bal.	Bal.	Bal.	Bal.	Bal.
As	0.02-0.10	0.02-0.06	0.02-0.035	0.02-0.06	0.02-0.06
P	–	0.01 max	0.01 max	–	–
Mn	–	0.1 max	0.1 max	–	–
Total Impurities	–	0.3 max	0.1 max	0.3 max	–
Condition	O61	R390	F39	M	O
	–	R340	F34	TA	–
	–	–	–	O	–
Yield Strength N/mm²	125 min.	150 min.	150-230	–	–
	–	120 min.	120-180	–	–
	–	–	–	–	–
Tensil Strength N/mm²	345 min.	390 min.	–	–	373 min.
	–	340 min.	–	–	–
	–	–	–	–	–
Elongation (%)	–	45 min.	45 min.	–	40 min.
	–	55 min.	55 min.	–	–
	–	–	–	–	–
Hardness Hv5	–	–	–	150 min.	–
	–	–	–	85-110	–
	–	–	–	75 max.	–
