EN10216-5 316L Seamless Tube For Hydraulic And Pneumatic Line

Product Details:

Place of Origin:	CHINA.
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	EN10216-5

Payment & Shipping Terms:

Minimum Order Quantity:	1000KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	5-80 Days
Payment Terms:	L/C, T/T
Supply Ability:	1500tons/month

Contact Now

All Products

Stainless Steel Seamless Pipe (308)

Stainless Steel Seamless Tube (297)

Duplex Stainless Steel Pipe (132)

Duplex Stainless Steel Tube (33)

Needle Tube (134)

Fin Tube (672)

Heat Exchanger (20)

Heat Exchanger Tube (443)

Heat Exchanger Tube Bundle (40)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (37)

Air Cooler (9)

Pressure Vessel (4)

Stainless Steel Welded Pipe (58)

Stainless Steel Welded Tube (120)

Nickel Alloy Pipe (266)

Nickel Alloy Tube (92)

Copper Alloy Tube (240)

Alloy Steel Tube (204)

Titanium Tube (15)

Bright Annealed Tube (155)

Boiler Tube (151)

Steel Fitting (826)

Steel Flange (615)

Others (401)

Cladding Parts (7)

Detailed Product Description

Standard:	EN10216-5	Material:	TP316L
Type:	Welded,Seamless	Length:	3000mm~6000mm,6 Meters Or Customized
Certification:	ISO,SGS,BV,ISO & SGS,ISO/CE/SGS	Surface:	Polished
Package:	Ply-wooden Case,Woven Bag	Finish:	Bright Annealed Or Un Annealed
Highlight:	EN10216-5 Seamless Tube , 316L Seamless Tube , Pneumatic Line Seamless Tube

EN10216-5 316L Seamless Tube

EN10216-5 316L seamless tube is a type of stainless steel tube that is used in various applications such as chemical processing, food processing, and medical equipment. It is made from grade 316L stainless steel, which is a low carbon version of 316 stainless steel that provides excellent corrosion resistance and high strength.

The EN10216-5 standard specifies the technical delivery conditions for seamless stainless steel tubes for pressure purposes. The 316L seamless tube is manufactured according to this standard and is available in various sizes and thicknesses.

The 316L seamless tube is characterized by its smooth surface finish, high dimensional accuracy, and excellent mechanical properties. It is also resistant to pitting, crevice corrosion, and stress corrosion cracking, making it ideal for use in harsh environments.

The 316L seamless tube is commonly used in industries such as chemical, petrochemical, pharmaceutical, and food processing. It is also used in medical equipment, heat exchangers, and instrumentation systems.

In conclusion, the EN10216-5 316L seamless tube is a high-quality stainless steel tube that offers excellent corrosion resistance, high strength, and durability. It is widely used in various applications and is a preferred choice for many industries.

Chemical Composition Of TP 316L Stainless Steel Seamless Tubes

GRADE		C	MN	SI	P	S	CR	MO	NI	N
316L	Min	-	-	-	-	-	16.0	2.00	10.0	-
316L	Max	0.03	2.0	0.75	0.045	0.03	18.0	3.00	14.0	0.10

Mechanical Properties TP 316L Stainless Steel Seamless Tubes

GRADE	TENSILE STR (MPA) MIN	YIELD STR 0.2% PROOF (MPA) MIN	ELONG (% IN 50MM) MIN	HARDNESS
GRADE	TENSILE STR (MPA) MIN	YIELD STR 0.2% PROOF (MPA) MIN	ELONG (% IN 50MM) MIN	ROCKWELL B (HR B) MAX	BRINELL (HB) MAX
316L	485	170	40	95	217

TP 316L Stainless Steel Seamless Tubes Physical Properties

GRADE	DENSITY (KG/M3)	ELASTIC MODULUS (GPA)	MEAN CO-EFF OF THERMAL EXPANSION (ΜM/M/°C)			THERMAL CONDUCTIVITY (W/M.K)		SPECIFIC HEAT 0-100°C (J/KG.K)	ELEC RESISTIVITY (NΩ.M)
GRADE	DENSITY (KG/M3)	ELASTIC MODULUS (GPA)	0-100°C	0-315°C	0-538°C	AT 100°C	AT 500°C	SPECIFIC HEAT 0-100°C (J/KG.K)	ELEC RESISTIVITY (NΩ.M)
316L	8000	193	15.9	16.2	17.5	16.3	21.5	500	74
