Seamless Carbon Steel Heat Exchanger Tube U Bend Tube ASTM A179 A210 A1

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ISO9001-2008, API 5L, API 5CT
Model Number:	ASTM A179, ASME SA179,A178

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Packaging Details:	PLYWOOD CASE,BUNDLE,WOVEN BAG
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (286)

Stainless Steel Seamless Tube (275)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (28)

Needle Tube (102)

Fin Tube (619)

Heat Exchanger (16)

Heat Exchanger Tube (425)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (112)

Nickel Alloy Pipe (259)

Nickel Alloy Tube (78)

Copper Alloy Tube (222)

Alloy Steel Tube (182)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (141)

Steel Fitting (797)

Steel Flange (583)

Others (388)

Cladding Parts (7)

Detailed Product Description

STANDARD:	A179,SA179,A178	MATERIAL:	GR.A ,B,C
Length:	6000MM,6096MM,SRL,DRL	OD:	3/4" (19.05), 1"(25.4) , 1-1/4"(31.75), 1-1/2"(38.1), 2" (50.8), 2-1/2"(63.5) , 3" (76.2)
WT:	0.89,1,1.2,1.5,2MM...	SURFACE:	BLACK,OILED
Highlight:	ASTM A179 U Bend Tube , ASTM A210 U Bend Tube , Seamless U Bend Tube

Seamless Carbon Steel Heat Exchanger Tube U Bend Tube ASTM A179 A210 A1

ASTM A179/A179M is Standard Specification for Seamless Cold-Drawn Low-Carbon Steel Heat Exchanger and Condenser Tubes.

Chemistry Composition:

C, %	Mn, %	P, %	S, %
0.06-0.18	0.27-0.63	0.035 max	0.035 max

Mechanical Properties:

Tensile Strength, MPa	Yield Strength, MPa	Elongation, %	Hardness, HRB
325 min	180 min	35 min	72 max

Specifications of ASTM A179/ASME SA179 U Bend Heat Exchanger Tubes

Bending Details: Can Accord to Bending Drawings.

Seamless Carbon Steel Heat Exchanger Tube U Bend Tube ASTM A179 A210 A1 0

ASTM A179 Steel Pipes Application:

A179 seamless steel pipe is widely used in industries such as petroleum, chemical, medical, food, light industry, machinery, instrument, include industrial pipeline and mechanical structure parts, etc.

ASTM A179/A179M U-bend tubes for heat exchangers appled mostly in oil and gas plants, chemical and petrochemical plants, refineries, power plants and renewable energy plants. Low fin tubes can be supplied in the form of U bends, Sizes tolerances of U bend tubes are to fillfil the requirements of: ASTM A556 /A556M and DIN 28179.

Outside Diameter & Tolerance

Outside Diameter, mm	Tolerance, mm
3.2≤OD＜25.4	±0.10
25.4≤OD≤38.1	±0.15
38.1＜OD＜50.8	±0.20
50.8≤OD＜63.5	±0.25
63.5≤OD＜76.2	±0.30
76.2	±0.38
