Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas

Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas

  • Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas
  • Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas
  • Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas
  • Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas
Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: API , ABS, DNV, GL , LR, NK
Model Number: ASTM A182 F310
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/Wooden Pallet/Customized
Delivery Time: Depends on quantity
Payment Terms: T/T,L/C
Supply Ability: 1000 tons per month
Contact Now
All Products
Stainless Steel Seamless Pipe (277)
Stainless Steel Seamless Tube (269)
Duplex Stainless Steel Pipe (128)
Duplex Stainless Steel Tube (27)
Needle Tube (86)
Fin Tube (596)
Heat Exchanger (10)
Heat Exchanger Tube (419)
Heat Exchanger Tube Bundle (37)
Heat Exchanger Tubesheet (117)
Heat Exchanger Baffle (35)
Air Cooler (7)
Pressure Vessel (2)
Stainless Steel Welded Pipe (57)
Stainless Steel Welded Tube (113)
Nickel Alloy Pipe (258)
Nickel Alloy Tube (75)
Copper Alloy Tube (210)
Alloy Steel Tube (173)
Titanium Tube (9)
Bright Annealed Tube (153)
Boiler Tube (138)
Steel Fitting (784)
Steel Flange (574)
Others (384)
Detailed Product Description
Grade: F310 Application: Petroleum,Chemical, Fittings And Connection
Pressure: Class150/300/600/9001500/2500 Color: Natural Color
Specification: ASTM A182 Packing: Wooden Case/Wooden Pallet/Customized
Highlight:

RTJ Weldneck Flange

,

Oil And Gas Weldneck Flange

,

ASTM A182 Weldneck Flange

Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas



A182 F310 weldneck flange is a type of flange made from A182 F310 stainless steel material. This flange is designed with a neck that is welded to the pipe, providing a strong and leak-proof connection. It is commonly used in high temperature and corrosive environments where high strength and resistance to oxidation are required.





Weld neck flanges are used in high pressure environments and are easily identifiable due to their tapered hub. Moreover, weld neck flanges are particularly suitable for use in repeated bending conditions. These flanges are connected to the piping system by welding the pipe to the flange neck. Therefore, stainless steel grades with good weldability are preferred for fabricating it. WNRF not only reduces stress concentration at the bottom of the hub but also helps in transferring stress from the flange to the pipe.



Features of stainless steel 310:


High temperature resistance:


310 stainless steel is known for its good high temperature resistance. Withstands temperatures up to 1150°C (2100°F) in continuous operation and up to 1230°C (2250°F) in intermittent operation.



Corrosion resistance:


This grade of stainless steel exhibits excellent corrosion resistance, especially in mildly corrosive environments. It resists oxidation and scaling, making it suitable for applications involving high temperatures.



Strength and durability:


Stainless steel 310 or pipe flanges are known for their high strength and durability. It maintains its mechanical properties at both high and low temperatures, providing reliability under a wide range of operating conditions.



ASME SA182 SS 310 flanges can generally be easily cold formed using standard methods and equipment. F310 flanges have machining properties comparable to F304 flanges. Also known as WNR 1.4841 flanges, these grades are welded using matching electrodes and filler metal. We also offer similar customized sizes and shapes as per the demands of our esteemed clients.



Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas 0



Stainless Steel ASTM A182 F310 Weldneck Flange RTJ For Oil And Gas 1



Chemical Composition of F310



Grade

C

Mn

Si

P

S

Cr

Mo

Ni

N

310

min.
max.

-
0.25

-
2.00

-
1.50

-
0.045

-
0.030

24.0
26.0

-

19.0
22.0

-



Mechanical Properties



Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB)
max
310 515 205 40 95 217





Physical Properties



Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion(μm/m/°C) Thermal Conductivity(W/m.K) Specific Heat 0-100°C (J/kg.K) Electrical Resistivity (nΩ.m)
0-100°C 0-315°C 0-538°C at 100°C at 500°C
310 7750 200 15.9 16.2 17.0 14.2 18.7 500 720



Equivalent Material



STANDARD

WERKSTOFF NR.

UNS

JIS

BS

GOST

EN

F310 Flanges

1.4841

S31000

SUS 310

310S24

20Ch25N20S2

X15CrNi25-20





Applications

  1. Oil and Gas Industries
  2. Food Processing Industries
  3. Equipments
  4. Pipeline
  5. Power Industries
  6. Ship Building Industries
  7. Paper Industries
  8. Cement Industries
  9. Chemical Industries
