DIN EN10216-5 1.4404 D2 T1 D4 T3 Stainless Steel Seamless Pipe Tube

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	1.4404,1.4301,1.4303,1.4571,1.4939,1.4462,1.4842

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

NDT:

ET, UT, HT, PMI

STANDARD:

ASTM A312, ASME SA312, EN10216-5, GOST9941-81, JIS G-3464

MATERIAL:

TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L

OD:

1/4" TO 100"

Highlight:

1.4404 Stainless Steel Seamless Pipe

D2 T1 Stainless Steel Seamless Pipe

DIN seamless stainless steel tubing

STAINLESS STEEL SEAMLESS PIPE DIN EN10216-5 1.4404 D2 T1 TUBE

YUHONG Group deal with Austenitic Stainless Steel, Nickel Alloy Steel(Hastelloy , Monel, Inconel, Incoloy ) seamless and welded pipe and tube already more than 34 years, every year sell more than 80000 tons of steel pipe and tube. Our client already cover more than 85 countries, Like Italy, UK, Gernmany, USA, Canada, Chile, Colombia, Saudi Arabia, Korea, Singapore, Austrial, Poland, France ....

Standard Specification:

EN10216-5 CT 1/2 : Stainless Steel Seamless Pipe & Tube

DIN EN10216-5 1.4404 D2 T1 D4 T3 Stainless Steel Seamless Pipe Tube 0

Material Grade:

Europen Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

Size Range:

Production	Outside Diameter	Wall Thickness
Seamless Pipe	6.00mm to 830mm	0.5mm to 48mm

Tolerances accordance to EN ISO 1127

Outer diameter (OD)	Wall thickness (WT)
D1 = +/- 1,50%, minimum +/- 0,75 mm	T1 = +/- 15,0%, minimum +/- 0,60 mm
D2 = +/- 1,00%, minimum +/- 0,50 mm	T1 = +/- 12,5%, minimum +/- 0,40 mm
D3 = +/- 0,75%, minimum +/- 0,30 mm	T1 = +/- 10,0%, minimum +/- 0,20 mm
D4 = +/- 0,50%, minimum +/- 0,10 mm	T1 = +/- 7,0%, minimum +/- 0,15 mm

Final Finishing:

Solution Annealed & Pickled

ANSI B16.10: B16.19 SCH 5S, SCH 10S, SCH 20, SCH 30, SCH 40S, SCH 60, SCH80S, XS, SCH 100, SCH 120, SCH160, XXS

Application:

Food processing equipment, particularly in beer brewing, milk processing & wine making.
Kitchen benches, sinks, troughs, equipment and appliances
Architectural panelling, railings & trim
Chemical containers, including for transport
Heat Exchangers
Woven or welded screens for mining, quarrying & water filtration
Threaded fasteners
Springs
Ship building, onshore , offshore, Maire.
Others
