ASTM A182 F51 / UNS S31803 Weld Neck Flange Duplex 2205 WNRF Flange

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A182 F51 Duplex Steel WNRF Flange

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Packaging Details:	Ply-wooden Case/Pallet
Delivery Time:	7 DAYS
Payment Terms:	L/C,T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Product Name:	Duplex Steel Flange	Standard:	ASTM A182 / ASME SA182
Material:	F51 UNS S31803	O.D.:	1/2" To 48"
W.T.:	SCH10, SCH20 ... SCH160, XXS	Class:	150#, 300#, 400#, 600#, 900#, 1500#, 2500#
Type:	WN, SO, BL, SW, LWN	Face:	RF, FF, RTJ
Application:	Petroleum,chemical,etc,fittings And Connection,beer
Highlight:	UNS S31803 Weld Neck Flange , Duplex 2205 Weld Neck Flange , ASTM A182 F51 Weld Neck Flange

ASTM A182 F51 / UNS S31803 / Duplex 2205 Weld Neck Flange WNRF Flange

Duplex Steel WNRF (Weld Neck Raised Face) Flange combines the unique properties of duplex stainless steel with a sturdy flange design. Generally, duplex steel flanges used in high-pressure, high-temperature systems or corrosive environments with available types such as blind, slip-on, weld neck, and socket weld.

Advantages of Duplex S31803 Flange:

High Strength: Greater strength compared to standard austenitic flanges, allowing for thinner walls.
Corrosion Resistance: Excellent in corrosive environments, including chloride-rich conditions.
Versatility: Suitable for various applications in industries like oil and gas, chemical processing, and marine.

ASTM A182 F51 Duplex Steel Flange Chemical Composition

C	Mn	Si	P	S	Cr	Mo	Ni	N	Fe
0.030 max	2.00 max	1.00 max	0.030 max	0.020 max	22.0 – 23.0	3.0 – 3.5	4.50 – 6.50	0.14 – 0.20	63.72 min

ASTM A182 F51 Duplex Steel Flange Mechanical Table

Density (g/cm 3)	Density (lb/in 3)	Melting Point (°C)	Melting Point (°F)
7.805	0.285	1420 – 1465	2588 – 2669

Other Types of Duplex Steel Flange

Duplex 2205 Flanges	EN TYPE	DIN
WN – Welding Neck	EN-TYPE 11	DIN 2631
		DIN 2632
		DIN 2633
		DIN 2634
		DIN 2635
BL – Blind	EN-TYPE 05	DIN 2527
SO – Slip On	EN-TYPE 01/12
LJ – Lap Joint	EN-TYPE 02/04	DIN 2641
		DIN 2642
		DIN 2655
		DIN 2656
LWN – Long Welding Neck / Integral	EN-TYPE 21
Welding Collars	EN-TYPE 32/34
Super Duplex 2507 Flat Flange for Welding		DIN 2573
Super Duplex 2507 Flat Flange for Welding		DIN 2576
SW – Socket Weld	EN-TYPE 14
THR – Threaded	EN-TYPE 13	DIN 2566
Super Duplex 2507 Lap Joint Short Stub End		DIN 2673
