ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger

ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger

  • ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger
  • ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger
  • ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger
  • ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger
ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number: Copper Alloy Tube
Payment & Shipping Terms:
Minimum Order Quantity: 1000KGS
Price: Negotiable
Packaging Details: Ply-wooden Case /Iron Case/ Bundle with plastic Cap/Woven Case
Delivery Time: Depends on quantity
Payment Terms: T/T, L/C
Supply Ability: 1000 tons per month
Contact Now
Detailed Product Description
Specification: ASTM B111, ASME SB111 Grade: C68700
Type: Seamless Surface: Pickled And Annealed, Polished, Bright Annealed
Non Destructive Test: Eddy Current Test -ASTM E426, Hystostatic Test-ASTM A999, Ultrsonic Test -ASTM E213 Size Standard: ASTM B16.10 & B16.19 & Customized
Highlight:

ASTM B111 Copper Alloy Tube

,

C68700 Copper Alloy Tube

,

Heat Exchanger Copper Alloy Tube

ASTM B111 C68700 Seamless Tube Copper Alloy Tube For Heat Exchanger



ASTM B111 C68700 is a specification for aluminum brass tubes, known for their excellent corrosion resistance and strength. This alloy is generally composed of copper, zinc, and aluminum, providing a balance of durability and performance in challenging environments.

It has Good heat transfer capabilities make it suitable for heat exchanger applications, Superior resistance to seawater and dezincification and Resists biofouling in marine environments.



Chemical Composition:

Grade Cu Zn Al As
C68700 76.0-79.0% 20.0-22.0% 1.8-2.5%

0.02-0.06%

(to inhibit dezincification)



Mechanical Properties:

Grade Yield Strength Tensile Strength Elongation Hardness
C68700 Typically around 105-125 MPa Approximately 310-380 MPa 30-45% in 50 mm 80-100 HRB



Applications:

ASTM B111 C68700 is widely used in various industries due to its excellent corrosion resistance and mechanical properties. Here are some detailed applications:



1. Marine Industry

  • Heat Exchangers and Condensers:Ideal for shipbuilding and offshore platforms due to resistance to seawater corrosion.
  • Seawater Piping Systems:Provides durability and longevity in marine environments.

2. Power Plants

  • Cooling Systems:Utilized in power plants for cooling water systems and heat exchangers, especially in coastal areas.
  • Condensers:Effective in steam turbine condensers, benefiting from its thermal conductivity.

3. Desalination Plants

  • Evaporator and Condenser Tubes:Essential in desalination processes where resistance to aggressive saline solutions is required.

4. Chemical Processing

  • Heat Exchangers:Used in chemical plants where resistance to corrosive chemicals and high temperatures is necessary.

5. Oil and Gas Industry

  • Offshore Platforms:Suitable for various components exposed to harsh marine environments, reducing maintenance needs.
