Stainless Steel Seamless Pipe EN 10216-5 D2/T1 1.4404 TP316L For Oil And Gas

Product Details:

Place of Origin:	China
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	EN 10216-5 D2/T1 1.4404 TP316L

Payment & Shipping Terms:

Minimum Order Quantity:	1000KGS
Price:	Negotiable
Packaging Details:	Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Delivery Time:	Depends on quantity
Payment Terms:	T/T, L/C
Supply Ability:	1500 tons per month

Contact Now

All Products

Stainless Steel Seamless Pipe (277)

Stainless Steel Seamless Tube (269)

Duplex Stainless Steel Pipe (128)

Duplex Stainless Steel Tube (27)

Needle Tube (86)

Fin Tube (596)

Heat Exchanger (10)

Heat Exchanger Tube (419)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (117)

Heat Exchanger Baffle (35)

Air Cooler (7)

Pressure Vessel (2)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (113)

Nickel Alloy Pipe (258)

Nickel Alloy Tube (75)

Copper Alloy Tube (210)

Alloy Steel Tube (173)

Titanium Tube (9)

Bright Annealed Tube (153)

Boiler Tube (138)

Steel Fitting (784)

Steel Flange (574)

Others (384)

Detailed Product Description

Material Grade:	1.4404 (316L)	Standard:	EN10216-5
Surface:	Pickled , Bright Annealed, Polished	NDT:	UT, ET, HT
Size:	SCH10S, SCH20, SCH30, SCH40, SCH STD, SCH60, SCH80 , SCH 100, SCH120, SCH140, SCH160 , XXS	Certificate:	ABS, BV, DNV, LR...
Highlight:	1.4404 Stainless Steel Seamless Pipe , TP316L Stainless Steel Seamless Pipe , Gas Stainless Steel Seamless Pipe

Stainless Steel Seamless Pipe EN 10216-5 D2/T1 1.4404 TP316L For Oil And Gas

EN 10216-5 refers to a European standard that specifies the technical delivery conditions for seamless steel tubes used for pressure purposes. Specifically, the designation "1.4404" corresponds to a type of stainless steel, which is an austenitic stainless steel grade commonly known as AISI 316L.

EN 10216-5 Pipe Dimension Tolerance

Hot rolled	Outside Diameterin mm	Tolerance
	30≤ Outer Diameter≤219.1	D2, ±1% or ±0.5mm
	219.1＜ Outer Diameter≤610	D1, ±1.5% or ±0.75mm
Cold Drawn	Outside Diameter in mm	Tolerance
	Outer Diameter≤219.1	D3, ±0.75% or ±0.3mm
	Outer Diameter≤219.1	D4, ±0.5% or ±0.1mm

EN 10216-5 Pipe Thickness Tolerance

Hot rolled	Outside Diameter, mm	Tolerance
	30≤Outer Diameter ≤219.1, WT≤0.01*Outer Diameter and WT≤4	T1, ±15% or ±0.6mm
	30≤Outer Diameter ≤219.1	T2, ±12.5% or ±0.4mm
	219.1＜Outer Diameter ≤610, WT≤0.05*Outer Diameter	+22.5%/-15%
	219.1＜Outer Diameter ≤610, 0.05Outer Diameter ＜WT≤0.09Outer Diameter	T1, ±15% or ±0.6 MM
	219.1＜Outer Diameter ≤610, WT>0.09*Outer Diameter	T2, ±12.5% or ±0.4 MM
Cold Drawn	Outside Diameter	Tolerance
	Outer Diameter ≤219.1	T3, ±10% or ±0.2 MM
	Outer Diameter ≤219.1	T4, ±7.5% or ±0.15 MM
