Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection

Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection

  • Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection
  • Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection
  • Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection
  • Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection
Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: EN ISO 13485:2016
Model Number: SUS304, SUS316L
Payment & Shipping Terms:
Minimum Order Quantity: 10 KGS
Price: Negotiable
Packaging Details: Carton Box, Plastic Box, Plywood Case
Delivery Time: 30-45 Days
Payment Terms: T/T, L/C
Supply Ability: 13 Billion pieces Per Year
Contact Now
Detailed Product Description
Features: Sterile, Disposable Standard: ISO9626, ISO7864, ISO6009
Materials: SUS304, SUS316L Size Gauge: 14G-32G
Wall Thickness: RW, TW, ETW Length: As Required
Technique: Cold Drawn Tube Type: Welded
Highlight:

Disposable Semi-finished Needle Tubes

,

SUS304 Stainless Steel Needle Tubes

,

Injection Semi-finished Needle Tubes

Disposable Hypodermic Needle , ISO9626 SUS304 , Stainless Steel Needle Tube For Injection



Disposable Hypodermic needles are normally made from SUS304 SUS316L stainless steel capillary tubes by tube drawing where steel tubes are drawn through progressively smaller dies to make needles in different sizes. The one end of each stainless steel needle is bevelled with a sharp tip, making the needle easily penetrate the skin. The tip can be one-face-bevel, two-face-bevel, three-face-bevel, and so on. Disposable Stainless Steel Hypodermic needle tubes are intended to inject and withdraw liquids, like blood mainly from the human body. Hypodermic needle tubes are most commonly used for blood transfusions, vaccinations and the delivery of other liquids, like medication, into the person's body. Hypodermic needles are hollow injection needles and they are generally used with a syringe.


YUHONG GROUP is the leading manufacturer of stainless steel semi-finished injection needle tubes in China. We can supply many kinds of stainless steel semi-finished medical needle tubes including hypodermic needles, blood collection needles, insulin needles, mesotherapy needles, and so on. And stainless Steel Hypodermic needle tubes are one of the most common injection needle tubes in our daily life, which are sterile and disposable. We can provide hypodermic needles ranging from 16G to 32G size. The wall thickness can be RW, TW, ETW for your selection. We can also customize needle tubes according to client's detailed drawings.



Characteristics Of Hypodermic Needles:

1. Single-Use
2. Corrosion Resistance
3. Excellent Size Tolerance
4. Smooth Surfce Finish
5. Sterile
6. High Precision
7. No impurities on the inside and outside surfaces



Sizes Chart:

OD OD Range ID
Gauge Norminal Min. Max. RW TW ETW
Min. Min. Min.
32G 0.23 0.229 0.241 0.089 0.105 0.125
31G 0.25 0.254 0.267 0.114 0.125 0.146
30G 0.30 0.298 0.320 0.133 0.165 0.190
29G 0.33 0.324 0.351 0.133 0.190 0.240
28G 0.36 0.349 0.370 0.133 0.190 -
27G 0.40 0.400 0.420 0.184 0.241 -
26G 0.45 0.440 0.470 0.232 0.292 -
25G 0.50 0.500 0.530 0.232 0.292 -
24G 0.55 0.550 0.580 0.280 0.343 -
23G 0.60 0.600 0.673 0.317 0.370 0.460
22G 0.70 0.698 0.730 0.390 0.440 0.522
21G 0.80 0.800 0.830 0.490 0.547 0.610
20G 0.90 0.860 0.920 0.560 0.635 0.687
19G 1.10 1.030 1.100 0.648 0.750 0.850
18G 1.20 1.200 1.300 0.790 0.910 1.041
17G 1.40 1.400 1.510 0.950 1.156 1.244
16G 1.60 1.600 1.690 1.100 1.283 1.390
15G 1.80 1.750 1.900 1.300 1.460 1.560
14G 2.10 1.950 2.150 1.500 1.600 1.727



Applications:

1. Hypodermic Needle
2. Injection Needle
3. Dental Devices
4. Infusion Needle
5. Veterinary Devices
6. Medical Equipments
7. Precision Instruments
8. Surgical Instruments
9. Ophthalmology Devices
