SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626

SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626

  • SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626
  • SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626
  • SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626
  • SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626
SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626
Product Details:
Place of Origin: China
Brand Name: YUHONG
Certification: EN ISO 13485:2016
Model Number: 10G-34G
Payment & Shipping Terms:
Minimum Order Quantity: 100 KGS
Price: Negotiable
Packaging Details: Carton Box, Plastic Box, Plywood Case
Delivery Time: 30-60 Work Days
Payment Terms: T/T, L/C
Supply Ability: 13 Billion pieces Per Year
Contact Now
Detailed Product Description
Standard: ISO9626-2016 Material Grade: SUS304
Gauge: 22-25G Wall Thickness: RW, TW, ETW
Length: 25mm, 38mm Or As Required Needle Tip: According To Client's Request
Highlight:

Intramuscular Injection Needle Tubes

,

Disposable Needle Tubes

,

ISO9626 Needle Tubes

SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626



An intramuscular injection needle tube injects medication into a muscle. Doctors usually use intramuscular injections to administer vaccines and other drugs. The injection sites of human body include the upper arm, hip, thigh, and buttocks. Intramuscular shots are generally given at a 90 degree angle. Intramuscular(IM) injection is used for people of all ages, including infants, children, teenagers, adult, old people. But a long or short length needle depends on patient's weight ang age. The intramuscular injection needle is usually used with syringe.



YUHONG GROUP specializes in stainless steel semi-finished needle tubes for more than 30 years which mainly used for intramuscular injection needle, hypodermic needle, blood collection needle, insulin needle, dental needle, and soon on. The most common material grade is SUS304, including 304Ni8.5, 304Ni9. And a small part of needle tubes are made by SUS316L. There are many advantages of usage of SS304, 316L material grades, such as excellent to corrosion and oxidation resistant, great abrasion resistance. Our stainless steel needle tubes are manufactured by cold drawn, bright annealed stainless steel capillary tubes. From raw material (stainless steel strips) to final finished needle tubes, we have more than 10 production lines. And we have laboratories and inspection department for testing and inspecting of needle tubes. Up to now, our needle tubes have been exported many foreign countried, like India, Iran, UAE, Europe, and so on.



Intramuscular Injection Site And Size:

Patient's age Injection Site Needle size
Newborn/infant
(Birth-1 year)
·Anterolateral thigh 1"needle
5/8"in premies or newborns (0-28 days old) if musdle mass inadequote
-25G needle
Toddler
(1-3 years)
·Anterolateral thigh preferred
·Deltoid when adequote mass
developed
1"-1.1/4"needle for thigh
5/8"-1"needle for deltoid
23-25G needle
Children
(3-11 years)
·Deltoid
·Anterolateral thigh
5/8"-1"needle for deltoid
1"-1.1/4"needle for thigh
23-25G needle
Adolescents/Adults
(11 years and older)
·Deltoid preferred
·Anterolateral thigh may be
used if necessary
1"-1.1/2"needle
23-25G needle



Different Needle Tube Types that we can provide:

Blood collection needle tube
Injection needle tube
Dental needle tube
Veterinary needle tube
Embroidery needle tube
Infusion needle tube
Anesthesia needle Tube
Bone marrow needle tube
Spinal needle tube
Insulin pen needle
Mesotherapy needle
Vein detained needle tube
Medical blade needle tube



All Size Gauges Of Stainless Steel Needle Tubes:

OD OD Range ID
Gauge Norminal Min. Max. RW TW ETW
Min. Min. Min.
- 0.15 - - - - -
34G 0.18 0.178 0.191 0.064 0.091 0.105
33G 0.2 0.203 0.216 0.089 0.105 0.125
32G 0.23 0.229 0.241 0.089 0.105 0.125
31G 0.25 0.254 0.267 0.114 0.125 0.146
30G 0.30 0.298 0.320 0.133 0.165 0.190
29G 0.33 0.324 0.351 0.133 0.190 0.240
28G 0.36 0.349 0.370 0.133 0.190 -
27G 0.40 0.400 0.420 0.184 0.241 -
26G 0.45 0.440 0.470 0.232 0.292 -
25G 0.50 0.500 0.530 0.232 0.292 -
24G 0.55 0.550 0.580 0.280 0.343 -
23G 0.60 0.600 0.673 0.317 0.370 0.460
22G 0.70 0.698 0.730 0.390 0.440 0.522
21G 0.80 0.800 0.830 0.490 0.547 0.610
20G 0.90 0.860 0.920 0.560 0.635 0.687
19G 1.10 1.030 1.100 0.648 0.750 0.850
18G 1.20 1.200 1.300 0.790 0.910 1.041
17G 1.40 1.400 1.510 0.950 1.156 1.244
16G 1.60 1.600 1.690 1.100 1.283 1.390
15G 1.80 1.750 1.900 1.300 1.460 1.560
14G 2.10 1.950 2.150 1.500 1.600 1.727
13G 2.40 2.300 2.500 1.700 1.956 -
12G 2.70 2.650 2.850 1.950 2.235 -
11G 3.00 2.950 3.150 2.200 2.464 -
10G 3.40 3.300 3.500 2.500 2.819 -



SUS304 Medical Stainless Steel Disposable Needle Tube For Intramuscular Injection , ISO9626 0
