ASTM A182 F904L / UNS N08904 Stainless Steel Slip On Flange B16.5 SORF Flange

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	ASTM A182 F904L Stainless Steel SORF Flange

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Packaging Details:	wooden case packing or according to client requirements
Delivery Time:	7 DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (290)

Stainless Steel Seamless Tube (277)

Duplex Stainless Steel Pipe (127)

Duplex Stainless Steel Tube (29)

Needle Tube (107)

Fin Tube (631)

Heat Exchanger (17)

Heat Exchanger Tube (424)

Heat Exchanger Tube Bundle (37)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (36)

Air Cooler (8)

Pressure Vessel (4)

Stainless Steel Welded Pipe (57)

Stainless Steel Welded Tube (114)

Nickel Alloy Pipe (261)

Nickel Alloy Tube (79)

Copper Alloy Tube (227)

Alloy Steel Tube (184)

Titanium Tube (10)

Bright Annealed Tube (153)

Boiler Tube (145)

Steel Fitting (804)

Steel Flange (590)

Others (391)

Cladding Parts (7)

Detailed Product Description

Product Name:	Stainless Steel Flanges	Dimension:	ASTM, ASME, ANSI, DIN, And EN
Standard:	ASTM A182 / ASME SA182	Material Grade:	904L, UNS N08904
Size:	1/2" To 48"	Pressure/Class:	150#, 300#, 400#, 600#, 900#, 1500#, 2500# Or As Per Custom Requirement
Type:	SORF, SOFF, WNRF, SWRF, RTJF, BLIND	Processes:	Hot Forging / Rolling / Machining
Applications:	Oil And Gas Industries, Pipeline, Shipbuilding Industries,Chemical Industries
Highlight:	B16.5 SORF Flange , UNS N08904 Stainless Steel Slip On Flange , ASTM A182 F904L SORF Flange

ASTM A182 F904L / UNS N08904 Slip On Stainless Steel Flanges B16.5 Forged SORF Flange

ASTM A182 F904L stainless steel Flange is a premium material designed for highly demanding applications where common stainless steels like 304 and 316 would fail. Its superior corrosion resistance (in the corrosive environments, including sulfuric acid, phosphoric acid, and chloride-containing solutions.), durability, and performance in extreme environments justify its higher cost. 904L has a polished, attractive finish, making it suitable for architectural and decorative applications. In contrast, 304 and 316 are more economical and suitable for general-purpose usage with less demanding conditions.

Flange Specifications

Dimensions: ASME B16.5 (up to 24" NPS) or B16.47 for larger sizes.
Pressure Ratings: Class 150 to 2500 (dependent on size and design).
Face Finish: Raised Face (RF) typically has a serrated finish (125-250 µin) for better gasket grip.

Equivalent Grades of ASTM A182 F904L Stainless Steel SORF Flange

STANDARD	WERKSTOFF NR.	UNS	EN	AFNOR	JIS	BS	KS
SS 904L	1.4539	N08904	X1NiCrMoCu25-20-5	Z2 NCDU 25-20	SUS 904L	904S13	STS 317J5L

Chemical Composition of ASTM A182 F904L Stainless Steel SORF Flange

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Cu
SS 904L	0.020 max	2.00 max	1.00 max	0.040 max	0.030 max	19.00 – 23.00	4.00 – 5.00 max	23.00 – 28.00	1.00 – 2.00

Mechanical Properties of ASTM A182 F904L Stainless Steel SORF Flange

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.95 g/cm3	1350 °C (2460 °F)	Psi – 71000 , MPa – 490	Psi – 32000 , MPa – 220	35 %

Summary Table: 904L vs. Common Stainless Steels

Property	904L Stainless Steel	304 Stainless Steel	316 Stainless Steel
Nickel Content	23-28%	8-12%	10-14%
Molybdenum Content	4-5%	0%	2-3%
Copper Content	1-2%	0%	0%
Corrosion Resistance	Exceptional	Moderate	Good
Cost	High	Low	Moderate
Applications	Highly corrosive environments	General-purpose	Marine, medical, chemical
